Ergotron 45-353-026 – LX Sit-Stand Wall Mount LCD Arm, Polished Aluminum
Overview
The Ergotron 45-353-026 is an LX Sit-Stand Wall Mount LCD Arm designed to provide ergonomic height adjustment for compatible displays in space-constrained work environments. Its polished aluminum construction and wall-mounted configuration allow a display to be positioned for seated or standing use while keeping the work surface clear.
The arm provides 20 inches (51 cm) of vertical adjustment and can extend the mounted display up to 33 inches (84 cm). Ergotron Constant Force technology provides smooth adjustment, while the wall-mounted design allows the display to fold back close to the wall when not required.
Technical Information
The 45-353-026 supports displays up to 42 inches with a specified load range of 7–25 lb (3.2–11.3 kg). Monitor depth can affect the applicable weight capacity. The arm provides 20 inches (50.8 cm) of height adjustment, 360° pan and 360° display rotation.
The display interface supports VESA MIS-D, MIS-E and MIS-F mounting standards, including 75 x 75 mm, 100 x 100 mm, 200 x 100 mm and 200 x 200 mm patterns. An optional Ergotron 97-759 VESA adapter can expand MIS-F compatibility to 400 x 200 mm, 400 x 300 mm and 400 x 400 mm patterns.
The display tilts up to 70° upward and 5° downward, providing a 75° total tilt range. The wall-mount base includes a rotation stop that limits the extension-to-base connection to 180° to help prevent the extension from contacting the wall.
Compatibility
The Ergotron 45-353-026 is designed for compatible LCD monitors and displays that meet the specified size, weight and VESA requirements. Ergotron specifies a typical display size of up to 42 inches and a maximum load of 25 lb (11.3 kg). Display size may exceed the stated guideline when the display remains within the mount's weight capacity and mounting requirements.
The arm attaches directly to a sturdy vertical surface and can be installed to a suitable wood stud where applicable. It can also be attached to a compatible Ergotron Wall Track using the separately ordered 97-091 bracket.
The 45-353-026 can also be configured for notebook use with the separately available Ergotron Notebook Tray 50-193-200 instead of a conventional LCD display.
Key Features
- Supports compatible displays up to 42 inches and 25 lb (11.3 kg).
- Provides 20 inches (51 cm) of vertical adjustment for seated-to-standing operation.
- Extends the display up to 33 inches (84 cm) with 360° pan and 360° rotation.
- Supports VESA MIS-D, MIS-E and MIS-F mounting patterns with optional larger-pattern adapter support.
- Polished aluminum construction with Constant Force technology, locking connections and a 10-year warranty.
Applications
The Ergotron 45-353-026 is suitable for sit-stand workstations, offices, control environments, digital signage, healthcare work areas, collaborative spaces and other installations where a display must be positioned at different working heights without occupying desk space. Its 33-inch extension and wall-mounted configuration also make it suitable for space-constrained installations.
DC Supplies Product Note
The exact MPN 45-353-026 identifies the LX Sit-Stand Wall Mount LCD Arm in polished aluminum. It should not be confused with the heavier-duty 45-383-026 LX HD Sit-Stand Wall Mount LCD Arm, which has a different capacity and display-size specification. The 45-353-026 is the standard LX sit-stand wall-mounted arm.
Specifications
| Brand | Ergotron |
|---|
| Part Number | 45-353-026 |
|---|
| Product Type | LX Sit-Stand Wall Mount LCD Arm |
|---|
| Color / Finish | Polished aluminum |
|---|
| Mounting Type | Wall mount |
|---|
| Typical Display Size | Up to 42 in |
|---|
| Weight Capacity | 7–25 lb (3.2–11.3 kg) |
|---|
| Vertical Adjustment | 20 in (51 cm) |
|---|
| Maximum Extension | 33 in (84 cm) |
|---|
| Folded Depth | 4.5 in (11.4 cm) |
|---|
| Tilt | 70° up / 5° down |
|---|
| Pan | 360° |
|---|
| Display Rotation | 360° |
|---|
| VESA Standard | MIS-D / MIS-E / MIS-F |
|---|
| VESA Mounting Patterns | 75 x 75, 100 x 100, 200 x 100, 200 x 200 mm |
|---|
| Optional VESA Adapter | 97-759 for 400 x 200, 400 x 300 and 400 x 400 mm MIS-F patterns |
|---|
| Side-to-Side Adjustment | 62 in (157 cm) |
|---|
| Product Weight | 11 lb (5 kg) |
|---|
| Shipping Dimensions | 22.1 x 10.9 x 7.3 in (56 x 28 x 19 cm) |
|---|
| Shipping Weight | 12.6 lb (5.7 kg) |
|---|
| Warranty | 10 years |
|---|
FAQs
What is the Ergotron 45-353-026?
The 45-353-026 is Ergotron's LX Sit-Stand Wall Mount LCD Arm in polished aluminum, designed to provide wall-mounted ergonomic positioning for compatible displays.
What is the maximum display weight?
The maximum specified display load is 25 lb (11.3 kg), with a specified operating range of 7–25 lb (3.2–11.3 kg). Monitor depth can affect the applicable capacity.
What display size does it support?
Ergotron specifies a typical display size of up to 42 inches. The display must remain within the mount's specified weight and VESA limits.
How much vertical adjustment does the arm provide?
The 45-353-026 provides 20 inches (51 cm) of vertical adjustment for moving the display between seated and standing positions.
How far can the display extend from the wall?
The arm extends the mounted display up to 33 inches (84 cm) from its mounting position.
What VESA mounting patterns are supported?
The arm supports VESA MIS-D patterns of 75 x 75 mm and 100 x 100 mm, MIS-E at 200 x 100 mm, and MIS-F at 200 x 200 mm.
Can larger VESA patterns be used?
Yes. The optional Ergotron 97-759 VESA Bracket Adapter Kit supports MIS-F patterns of 400 x 200 mm, 400 x 300 mm and 400 x 400 mm.
Can the arm be mounted to a wall track?
Yes. A compatible Ergotron Wall Track installation requires the separately ordered 97-091 bracket.
Can a laptop be mounted instead of an LCD?
Yes. Ergotron specifies that the arm can be configured for notebook use with the separately available Notebook Tray 50-193-200.
Does the arm provide cable management?
Yes. The design routes cables beneath the arm to keep them organized and clear of the working area.
What warranty does the 45-353-026 have?
The current product documentation and distributor listings specify a 10-year warranty for the 45-353-026.
