Ergotron 45-273-216 – StyleView Sit-Stand Combo System with Small CPU Holder, White
Overview
The Ergotron 45-273-216 is a StyleView Sit-Stand Combo System configured with a small CPU holder and 34-inch wall track in white. It provides a complete wall-mounted workstation for a monitor, keyboard, mouse, barcode scanner and computer, allowing the workstation to move between seated and standing positions.
The system uses Ergotron Constant Force technology for smooth height adjustment. The monitor and keyboard move together through a 20-inch (51 cm) tandem range, while the LCD provides an additional 5 inches (13 cm) of independent height adjustment. The workstation can fold toward the wall when not in use, helping conserve space in clinical and other compact environments.
Technical Information
The 45-273-216 supports a typical LCD size of up to 24 inches and uses VESA MIS-D mounting. The display is rated for 6–18 lb (2.7–8.2 kg), with support for displays up to 25 lb (11.4 kg) when the specified tilt and lift lock-out features are engaged. The LCD provides 30° total tilt, 360° pan and 360° portrait-to-landscape rotation.
The keyboard, mouse and barcode scanner have a combined capacity of 4 lb (1.8 kg). The included small CPU holder accommodates CPUs from 1-3/8 to 3-3/4 inches (35–95 mm) in width. The complete system includes a 34-inch wall track, CPU mounting hardware, cable channels, integrated keyboard tray, scanner and mouse holders, and VESA mounting hardware.
Compatibility
The 45-273-216 is designed for a single display using VESA MIS-D mounting with 75 x 75 mm or 100 x 100 mm hole patterns. Ergotron identifies displays up to 24 inches as the typical supported size, subject to the applicable display weight rating.
The small CPU holder is intended for CPUs approximately 1-3/8 to 3-3/4 inches (35–95 mm) wide. The system is supplied with wall-track hardware for concrete and wood installations. Installation should be performed on a structurally suitable wall using the appropriate supplied or specified mounting hardware.
Key Features
- Exact Ergotron part number 45-273-216 in white
- StyleView Sit-Stand Combo System with small CPU holder and 34-inch wall track
- 20-inch (51 cm) tandem LCD and keyboard height adjustment plus 5-inch independent LCD adjustment
- Supports displays up to 24 inches with VESA MIS-D mounting
- Integrated keyboard, mouse, barcode scanner, cable-management and CPU mounting components
Applications
The Ergotron 45-273-216 is designed for healthcare and clinical workstations, patient-care environments, laboratories, registration stations and other installations where computer equipment must be accessible while sitting or standing. Its wall-mounted architecture is particularly useful where floor and desk space are limited.
DC Supplies Product Note
The 45-273-216 is the white small-CPU-holder configuration of the StyleView Sit-Stand Combo System. Do not substitute the related 45-271-216, which uses a medium CPU-holder configuration. The exact MPN should be verified when matching an existing Ergotron wall-track installation or CPU mounting requirement.
Specifications
| Specification | Details |
|---|
| Brand | Ergotron |
| Part Number | 45-273-216 |
| Product | StyleView Sit-Stand Combo System |
| Configuration | Small CPU holder and wall track |
| Color | White |
| Mounting Type | Wall mount |
| Wall Track | 34 in (86.4 cm) |
| Typical LCD Size | Up to 24 in |
| Display Capacity | 6–18 lb (2.7–8.2 kg); up to 25 lb (11.4 kg) with tilt/lift lock-out features engaged |
| Keyboard/Mouse/Scanner Capacity | 4 lb (1.8 kg) |
| Tandem Height Adjustment | 20 in (51 cm) |
| Independent LCD Adjustment | 5 in (13 cm) |
| Maximum LCD Height Adjustment | 25 in (64 cm) |
| Monitor Tilt | 30° total; +25° / -5° |
| Monitor Pan | 360° |
| Monitor Rotation | 360° portrait-to-landscape |
| VESA Standard | MIS-D |
| VESA Patterns | 75 x 75 mm and 100 x 100 mm |
| Maximum Wall Extension | 39.75 in (101 cm); up to 56.75 in (144 cm) with optional extender |
| Folded Depth | 12 in (30.5 cm) |
| CPU Holder | Small; 1-3/8 to 3-3/4 in (35–95 mm) width |
| Keyboard Tray | 18.6 x 9 in (47.2 x 22.8 cm) |
| Product Weight | 38.4 lb (17.5 kg) |
| Shipping Dimensions | 37.1 x 22.1 x 11.1 in (94.2 x 56.1 x 28.2 cm) |
| Warranty | 5 years |
FAQs
What is the Ergotron 45-273-216?
The 45-273-216 is an Ergotron StyleView Sit-Stand Combo System with a small CPU holder and 34-inch wall track in white.
What monitor size does the 45-273-216 support?
Ergotron specifies a typical LCD size of up to 24 inches. The display must remain within the applicable weight capacity.
What is the standard display weight capacity?
The display capacity is 6–18 lb (2.7–8.2 kg). Displays up to 25 lb (11.4 kg) can be supported when the specified tilt and lift lock-out features are engaged.
How much height adjustment does the system provide?
The LCD and keyboard move together through 20 inches (51 cm), with an additional 5 inches (13 cm) of independent LCD adjustment. Maximum LCD height adjustment is 25 inches (64 cm).
What CPU holder is included?
The exact 45-273-216 configuration includes the small CPU holder. It accommodates CPUs from 1-3/8 to 3-3/4 inches (35–95 mm) in width.
What VESA patterns are supported?
The display mount uses VESA MIS-D and supports 75 x 75 mm and 100 x 100 mm mounting patterns.
Does the system include the wall track?
Yes. The 45-273-216 includes a 34-inch wall track with two black track covers and the associated track-mount hardware.
Can the monitor rotate between portrait and landscape?
Yes. The LCD mount provides 360° rotation for portrait-to-landscape positioning.
What is the difference between 45-273-216 and 45-271-216?
Both are white StyleView Sit-Stand Combo Systems. The 45-273-216 uses the small CPU-holder configuration, while 45-271-216 uses the medium CPU-holder configuration.
