Ruckus 10G-SFPP-TWX-P-0101 10G SFP+ Passive Direct Attach Copper Cable View larger
Previous Next

Ruckus 10G-SFPP-TWX-P-0101 1m 10G SFP+ Passive Direct Attach Copper Cable

New

In Stock

10 GbE passive twinax SFP+ cable, 1 m
×




$105.00

  • New

Detailed Specifications

Ruckus 10G-SFPP-TWX-P-0101 – 10 GbE SFP+ Passive Twinax Cable

Overview :

The Ruckus 10G-SFPP-TWX-P-0101 is a 10 Gigabit Ethernet SFP+ module with a fixed 1-metre passive twinax copper cable designed to interconnect adjacent network hardware with minimal latency and power draw. Its plug-in form factor enables hot-swappable insertion into SFP+ ports, making it suitable for rack-to-rack or switch-to-switch short-reach links where fibre may be excessive or cost-prohibitive. Because the cable is passive, it requires no external power or active modules, reducing component count and heat. The product fits within campus, data-centre, or edge aggregation deployments where Cisco/ICX/Ruckus SFP+ ports are available and cable length is limited to one metre. It integrates transparently into existing IEEE 802.3ae compliant 10 GbE infrastructure and supports full data-rate transmission between two SFP+ ports without signal regeneration.

Key Features :

  • 10 Gbps data rate for high-speed links

  • Fixed 1 m passive twinax copper cable length

  • SFP+ to SFP+ connector interface (plug-in)

  • Low power consumption passive design (<0.5 W)

  • Compliant with IEEE 802.3ae and SFF-8431 standards

Specifications

SpecificationDetails
Brand Ruckus
Part Number 10G-SFPP-TWX-P-0101
Product Type 10 GbE Direct Attach Copper Cable (Passive SFP+ to SFP+)
Data Transfer Rate 10 Gbps
Cable Type Passive twinax copper
Fixed Length 1 m (≈ 3.28 ft)
Connector Interface SFP+ on both ends
Form Factor Plug-in module
Cable AWG 30 AWG
Minimum Bend Radius 23 mm
Jacket Material PVC (OFNR)
Power Consumption < 0.5 W
Operating Temperature Range 0 °C to 70 °C
Compliance Standards IEEE 802.3ae, SFF-8431, RoHS
Dimensions (H × W × D) 1.574 in × 6.496 in × 9.566 in
Weight 0.4 lbs
