HPE P44114-B21 ProLiant DL20 Gen10 Plus E-2314 2.8GHz 4-core 1P 16GB View larger
Previous Next

HPE P44114-B21 ProLiant DL20 Gen10 Plus E-2314 2.8GHz 4-core 1P 16GB

New

HPE P44114-B21 ProLiant DL20 Gen10 Plus E-2314 2.8GHz...

×




  • New

Detailed Specifications

HPE P44114-B21

ProLiant DL20 Gen10 Plus (P44114-B21) – 1U Rack Server, Intel Xeon E‑2314, 16 GB RAM

The HPE ProLiant DL20 Gen10 Plus (P44114-B21) delivers enterprise-level performance in a compact 1U rackmount form factor. Powered by a Xeon E‑2314 quad-core CPU and advanced iLO 5 security, this server is ideal for edge computing, virtual workloads, and remote environments where space efficiency is key.

Features

Built on the Intel Xeon E‑2300 series, the DL20 offers strong single-threaded performance thanks to its 2.8 GHz base clock and 4.5 GHz Turbo Boost. With four SFF drive bays (expandable to six), it supports flexible storage options including SATA, SAS, and optional M.2 Networking can be upgraded via FlexibleLOM modules, enabling 10 GbE deployment for high-throughput use cases.

Advanced Options

Expandability is provided with two PCIe 4.0 slots, perfect for additional drive controllers or accelerators. Its short-depth chassis (~15″) is ideal for space-restricted data racks, POS environments, or small server rooms

Product Key Features

  •  Intel Xeon E‑2314 (4 cores, 2.8 GHz, 8 MB L3, up to 4.5 GHz Turbo, 65 W)

  •  16 GB DDR4 ECC RAM (1×16 GB, up to 128 GB across 4 slots @ 3200 MT/s)

  •  4× hot-plug SFF bays, additional internal drive/bay options (up to 6 SFF or 2 LFF)

  •  Dual 1 GbE (Broadcom BCM5720) plus optional FlexibleLOM for 10GbE

  •  Two PCIe 4.0 slots (x16 & x8), enabling GPUs, high-speed NICs, or storage cards

  •  HPE iLO 5, Silicon Root of Trust, and remote management

Reliability & Performance

This model includes ECC memory and HPE’s Silicon Root of Trust framework via iLO 5 to ensure firmware integrity and remote manageability. It supports Smart Array or Intel VROC RAID to safeguard data, and uses energy-efficient power supplies (290 W, 500 W redundant optional) along with Platinum efficiency fans for reliable uptime

Key Features :

  • Intel Xeon E‑2314 CPU, 4 cores (2.8–4.5 GHz)

  • 16 GB DDR4 ECC RAM (up to 128 GB supported)

  • Four hot-plug SFF drive bays (expandable to six)

  • Dual 1 GbE NIC; FlexibleLOM option for 10 GbE

  • Two PCIe 4.0 slots (x16 & x8)

  • HPE iLO 5 remote management & firmware protection

  • RAID support via embedded or optional Smart Array/VROC

  • Short 1U chassis (~15″ depth)

SpecificationDetails
Model Number P44114‑B21
CPU Intel Xeon E‑2314 4-core, 2.8 GHz (Turbo 4.5 GHz), 8 MB L3, 65 W
Memory 16 GB DDR4 ECC (1×16 GB); 4 slots, up to 128 GB @3200 MT/s
Storage Bays 4× hot-plug SFF (2.5″); supports up to 6 SFF or 2 LFF
RAID Controller Embedded Intel VROC SATA or Smart Array option
Networking Dual 1 GbE (Broadcom); FlexibleLOM for 10 GbE
Expansion Slots PCIe 4.0 x16 (FHHL) and PCIe 4.0 x8 (LP)
Management HPE iLO 5, Silicon Root of Trust, Intelligent Provisioning
Power Supply 290 W standard; optional 500 W RPS
Dimensions (1U) ~1.7″ H × 17.1″ W × 15.05″ D
Form Factor 1U rackmount
