HPE Aruba JL386A 1920S 48G 4SFP Ppoe+ 370W Ethernet Switch View larger
Previous Next

HPE Aruba JL386A 1920S 48G 4SFP Ppoe+ 370W Ethernet Switch

JL386A

New

HPE Aruba JL386A is a 48-port PoE+ Gigabit Ethernet switch with 4 SFP uplinks
×




Detailed Specifications

HPE JL386A

Aruba 1920S 48G 4SFP PoE+ 370W Managed Switch

The HPE JL386A Aruba 1920S 48G 4SFP PoE+ switch is a high-performance, smart-managed Layer 2+ switch built to meet the needs of growing businesses and branch networks. With 48 Gigabit Ethernet ports and a robust 370W PoE+ power budget, this switch can support a wide range of powered devices—like IP phones, wireless access points, and surveillance cameras—without the need for separate power infrastructure.

Features :

The 1920S series offers advanced functionality including VLANs, static Layer 3 routing, access control lists (ACLs), link aggregation, and Quality of Service (QoS)—features typically found in higher-end enterprise switches. These tools ensure secure traffic segmentation, efficient bandwidth utilization, and consistent network performance, all from an intuitive web GUI designed for non-technical users and IT pros alike.

Advanced Options :

Ideal for business networks that demand scalability, the JL386A includes four dedicated SFP ports for uplinking or fiber backhaul. With a compact 1U rack-mountable chassis, this switch integrates smoothly into existing racks or network cabinets, providing powerful performance in a space-saving design. The Aruba 1920S switch line is backed by a limited lifetime warranty and industry-leading support, offering peace of mind and long-term investment protection. For businesses looking to build a secure, scalable network with PoE+ power delivery, the JL386A is an ideal foundation.

Product Key Features

  • 48 x Gigabit Ethernet ports with full PoE+ support

  • 370W PoE+ budget to power IP cameras, phones, and access points

  • 4 x dedicated Gigabit SFP uplinks for flexible fiber connectivity

  • Layer 2+ intelligent management with static routing and ACLs

  • Easy-to-use web-based interface for simplified administration

  • Fan-cooled rack-mountable design ideal for growing business networks

Reliability & Performance :

The JL386A supports intelligent Layer 2+ features, including basic routing between VLANs, static routes, and advanced ACL-based access control. Its 370W PoE+ capacity delivers reliable power across all 48 ports, making it a powerful aggregation point for edge devices. With fan-based cooling and robust construction, it ensures continuous operation in enterprise wiring closets and network hubs. Designed to be intuitive, the switch offers a simple web-based management interface while also supporting SNMP for centralized monitoring.

Key Features :

  • 48 x 10/100/1000BASE-T PoE+ ports

  • 4 x dedicated SFP (1G) uplink ports

  • 370W total PoE+ power budget

  • Smart-managed with Layer 2+ features

  • VLANs, static routing, QoS, ACL support

  • Intuitive web GUI and SNMP-based management

  • Fan-cooled 1U rack-mountable chassis

  • Ideal for edge, campus, or small enterprise networks

  • Energy-efficient with intelligent power-saving features

Specifications :

SpecificationDetails
Model Number JL386A
Product Type Smart-Managed Layer 2+ PoE+ Switch
Ports 48 x 10/100/1000BASE-T (PoE+)
Uplink Ports 4 x SFP (Gigabit)
PoE Power Budget 370W
Switching Capacity 104 Gbps
Forwarding Rate 77.4 Mpps
Layer Support Layer 2 with static routing
VLAN Support Yes, up to 256 VLANs
MAC Address Table 16K entries
Management Web GUI, SNMP
Security ACLs, 802.1X, Port Security, DoS Protection
Stacking Capability No
Energy Efficiency IEEE 802.3az (EEE), Auto Power Down
Cooling Fan-cooled
Mounting 1U Rack-mountable
Power Supply Internal
Operating Temp 0°C to 40°C (32°F to 104°F)
Weight Approx. 10.3 lb (4.7 kg)
