HP JC101A Flex Fabric 5800 Networking Ethernet Switch refurbished View larger

HP JC101A Flex Fabric 5800 48 Port Ethernet Switch

JC101A

New

48-port Gigabit Switch with 2 Slots
×




Detailed Specifications

HP JC101A – 5800-48G Switch with 2 Module Slots

Overview :

The HP JC101A is a 48-port Gigabit Ethernet fixed switch with two modular expansion slots, designed for enterprise network deployment by engineers solving aggregation or core layer connectivity challenges. It supports wire-speed switching across all 48 RJ-45 10/100/1000 ports and includes dual slot capacity for additional modules, enabling flexible uplink or service extension. The form-factor is 2 RU, making it suitable for data center racks, campus distribution, or high-density branch hubs where modular uplinks and large port counts are required. It integrates into HP’s 5800 series environment and can be managed alongside other switches via CLI, web interface or network management system.

Key Features :

  • 48 autosensing 10/100/1000 RJ-45 ports

  • Two modular interface slots for uplink/service modules

  • Up to 284 Gb/s switching capacity at 2 RU height

  • Supports full IPv4/IPv6 dual-stack routing and ACLs

  • Redundant power supply slots and modular fan trays

Specifications :

SpecificationDetail
Brand HP
Part Number JC101A
Product Type 48-port Gigabit Switch, 2 Slot
Fixed RJ-45 Ports 48 × 10/100/1000Base-T autosensing
Fixed SFP/SFP+ Ports 4 fixed Gigabit SFP ports
Interface Slots 2 extended module slots
Switching Capacity 284 Gb/s
Maximum Throughput 211 Mpps (64-byte packets)
MAC Address Table Size 32 K entries
Routing Table Size (IPv4) 16 K entries
Dimensions (W×D×H) 17.32 in × 18.31 in × 3.39 in
Weight 39.7 lbs
Operating Temperature 32 °F to 113 °F (0 °C to 45 °C)
Management Interfaces RJ-45 console, USB 2.0
