Lenovo 13AC001UUS ThinkCentre M90q Gen 6 Desktop Computer View larger

Lenovo 13AC001UUS ThinkCentre M90q Gen 6 Desktop Computer

13AC001UUS

New

1L Tiny AI Desktop Core Ultra 5 235 16GB 256GB vPro

×




Detailed Specifications

Lenovo 13AC001UUS ThinkCentre M90q Gen 6 Desktop Computer

Overview

The Lenovo 13AC001UUS is a high-efficiency 1-liter "Tiny" AI PC from the ThinkCentre M90q Gen 6 series, specifically engineered for enterprise environments where space optimization and intelligent performance are essential. This model is powered by the Intel Core Ultra 5 235 (Series 2) processor, featuring 14 cores and an integrated Intel AI Boost NPU. This dedicated AI engine enables the system to handle background AI tasks—such as noise cancellation, video framing, and security analytics—with significantly higher efficiency, freeing up the CPU for primary business workloads.

This configuration is built with 16GB of high-speed DDR5-5600 memory and a 256GB PCIe Gen 4 NVMe SSD with TCG Opal 2.0 encryption, striking a balance between responsive performance and robust data security. Built on the Intel Q870 chipset, the 13AC001UUS supports the Intel vPro Enterprise platform, providing IT administrators with essential hardware-level management, out-of-band troubleshooting, and enhanced threat protection across the fleet.

Connectivity is a primary focus of the Gen 6 chassis, featuring a 20Gbps USB-C front port and built-in Wi-Fi 6E for high-bandwidth wireless networking. It natively supports up to three independent displays through its HDMI and DisplayPort outputs, making it an ideal choice for multi-monitor financial or administrative desks. With its MIL-STD-810H durability rating, tool-less chassis design, and included vertical stand, the 13AC001UUS offers a reliable, future-ready desktop experience in a remarkably small footprint.

Key Features

  • Intel Core Ultra 5 235 (14 cores) with AI Boost NPU for local AI acceleration

  • 16GB DDR5-5600 RAM and secure 256GB PCIe 4.0 Opal-encrypted SSD

  • Intel vPro Enterprise for advanced hardware security and remote management

  • Ultra-compact 1L chassis with MIL-SPEC durability and tool-less access

  • Support for up to 3 independent displays natively via HDMI and dual DisplayPort

Specifications

FeatureDetails
BrandLenovo
Part Number13AC001UUS
Product TypeTiny Desktop (1L)
ProcessorIntel Core Ultra 5 235 (14C / 14T, up to 5.0GHz)
AI NPUIntel AI Boost (13 TOPS)
GraphicsIntegrated Intel Graphics
Memory16GB (1x 16GB) DDR5-5600 SO-DIMM (Max 64GB)
Storage256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
ChipsetIntel Q870
NetworkingWi-Fi 6E AX211, Bluetooth 5.3, Gigabit Ethernet
Front Ports1x USB-C (20Gbps), 1x USB 3.2 Gen 2 (Always On), 1x USB 3.2 Gen 2
Rear Ports1x HDMI 2.1 TMDS, 2x DisplayPort 1.4, 3x USB 3.2 Gen 2, 1x USB 3.2 Gen 1
Expansion Slots1x PCIe 4.0 x8 (Low-Profile), 2x M.2 (Available for SSD)
Power Supply135W External Power Adapter (90% Efficiency)
Operating SystemWindows 11 Pro
