| Processor |
|---|
| Processor Generation |
1st Generation Intel® Xeon® Scalable |
| Thermal Design Power (TDP) |
85 W |
| Tcase |
77 °C |
| Supported instruction sets |
AVX, AVX 2.0, AVX-512, SSE4.2 |
| Scalability |
2S |
| Processor threads |
16 |
| Processor package size |
76.0 x 56.5 mm |
| Processor operating modes |
64-bit |
| Processor lithography |
14 nm |
| Processor codename |
Skylake |
| Memory types supported by processor |
LPDDR4-SDRAM |
| Memory clock speeds supported by processor |
2400 MHz |
| Maximum number of PCI Express lanes |
48 |
| Maximum internal memory supported by processor |
768 GB |
| Execute Disable Bit |
Yes |
| Embedded options available |
Yes |
| Processor cache type |
L3 |
| Processor cache |
11 MB |
| Conflict-Free processor |
Yes |
| Processor frequency |
2.1 GHz |
| Number of processors installed |
2 |
| Processor model |
4110 |
| Processor boost frequency |
3 GHz |
| Processor socket |
LGA 3647 (Socket P) |
| Processor cores |
8 |
| Processor manufacturer |
Intel |
| Processor family |
Intel® Xeon® |
| Memory |
|---|
| Internal memory |
32 GB |
| Memory slots |
16 |
| Maximum internal memory |
512 GB |
| Maximum internal memory |
512000 MB |
| Internal memory type |
DDR4-SDRAM |
| Storage |
|---|
| Hot-swap |
Yes |
| SSD interface |
E-SATA |
| SSD capacity |
184.32 GB |
| RAID support |
Yes |
| RAID levels |
0, 1, 5, 6, 10, JBOD |
| Optical drive type |
No |
| Number of SSDs installed |
24 |
| Maximum storage capacity |
552.96 TB |
| HDD size |
2.5" |
| HDD interface |
Serial ATA |
| Network |
|---|
| Supported network protocols |
CIFS, AFP, NFS, FTP, WebDAV |
| Wake-on-LAN ready |
Yes |
| Ethernet LAN |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| Expansion slots |
|---|
| PCI Express slots version |
3.0 |
| PCI Express x8 (Gen 3.x) slots |
2 |
| Optical drive |
|---|
| Optical drive type |
No |
| Design |
|---|
| Optical drive type |
No |
| Chassis type |
Desktop |
| Product colour |
Black |
| Performance |
|---|
| Compatible operating systems |
Windows Server 2016 |
| Noise level |
53.7 dB |
| Operating system installed |
Windows Server 2016 Standard |
| Harmonized System (HS) code |
84714100 |
| Software |
|---|
| Compatible operating systems |
Windows Server 2016 |
| Operating system installed |
Windows Server 2016 Standard |
| Processor special features |
|---|
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel TSX-NI |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel TSX-NI version |
1.00 |
| Processor ARK ID |
123547 |
| Power |
|---|
| Number of redundant power supplies installed |
1 |
| Number of power supply units |
1 |
| Power requirements |
100 - 240 |
| Redundant power supply (RPS) support |
Yes |
| Power supply input frequency |
50 - 60 Hz |
| Power supply |
800 W |
| Power consumption (typical) |
288.49 W |
| Power consumption (standby) |
145.8 W |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
0 - 35 °C |
| Certificates |
|---|
| Certification |
EAC, VCCI, RCM, KC, FCC, CE, BSMI |
| Technical details |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Noise level |
53.7 dB |
| Ventilation fan(s) |
80 x 80mm x4 |
| Power consumption (standby) |
145.8 W |
| Number of users |
6000 user(s) |
| Chassis type |
Desktop |
| PCI Express x8 (Gen 3.x) slots |
2 |
| Weight & dimensions |
|---|
| Width |
19" (482 mm) |
| Weight |
38.1 lbs (17.3 kg) |
| Height |
3.46" (88 mm) |
| Depth |
28.5" (724 mm) |
| Packaging content |
|---|
| Cables included |
AC |
| Other features |
|---|
| Ventilation fan(s) |
80 x 80mm x4 |
| Power consumption (standby) |
145.8 W |
| Number of users |
6000 user(s) |
