Netgear AGM731F SFP Transceiver 1000BASE-SX SFP 1G Ethernet View larger

NETGEAR AGM731F 1000BASE-SX 1G Ethernet SFP Transceiver

New

In Stock

1 Gbps SX SFP, 550 m multimode reach
×




$138.00

  • New

Detailed Specifications

Netgear AGM731F – Gigabit SX SFP Module

Overview :

The Netgear AGM731F is a 1 Gigabit SX small-form-factor transceiver module used in fiber optic networks. It enables multimode fiber links up to ~550 meters at 850 nm, for switches or other chassis with SFP ports. It is suited for campus, access, or distribution layer fiber runs between switches or network equipment. It supports hot-plug operation and digital diagnostics (DOM) for real-time status monitoring.

Key Features

  • Supports 1000Base-SX over multimode fiber

  • Duplex LC connector interface

  • Digital Optical Monitoring (DOM) support

  • Hot-pluggable +3.3 V single-supply

Specifications

ParameterValue
Brand Netgear
Part Number AGM731F
Product Type 1G SX SFP Transceiver
Standard / Protocol IEEE 802.3z 1000Base-SX
Wavelength 850 nm
Fiber Type Multimode fiber (50/125 µm or 62.5/125 µm)
Maximum Reach Up to 550 m (on OM3/50 µm MMF)
Connector Duplex LC
Supply Voltage +3.3 V
Operating Temperature 0 °C to 70 °C
Power Consumption / Dissipation < 1 W (typical)
Diagnostic Monitoring Yes (DOM)
Hot-Pluggable Yes
