Netgear AXM764-10000S Compatible 10GBase-LRL SFP+Transceiver View larger

Netgear AXM764-10000S 10GBase-LRL SFP+ Transceiver

New

10GBASE-LR Lite SFP+ Transceiver
×




  • New

Detailed Specifications

Netgear AXM764-10000S 10GBASE-LR Lite SFP+ Transceiver

Overview :

The Netgear AXM764-10000S is a 10GBASE-LR Lite SFP+ transceiver designed for 10 Gigabit Ethernet connectivity over single-mode fiber. It operates at a wavelength of 1310nm, supporting data rates up to 10.3 Gbps over distances up to 2 km. The transceiver features an LC duplex connector and is compatible with Netgear M5300, M6100, M7100, and M7300 series switches, as well as select Smart and Plus switches. It is hot-swappable, facilitating easy installation and maintenance.

Key Features :

  • Supports 10.3 Gbps data rate

  • Operates over single-mode fiber up to 2 km

  • 1310nm wavelength with LC duplex connector

  • Hot-swappable for easy integration

Technical Specifications :

SpecificationDetails
Brand Netgear
Part Number AXM764-10000S
Product Type 10GBASE-LR Lite SFP+ Transceiver
Data Rate Up to 10.3 Gbps
Wavelength 1310 nm
Cable Type Single-mode fiber (9/125 µm)
Connector Type LC duplex
Maximum Distance 2 km
Power Consumption <1.5W
Operating Temperature 0°C to 70°C
Compliance RoHS, MSA SFF-8431
Warranty 5 years
