Detailed Specifications
HPE P54649-001 MicroSvr G10+ v2 E-2314 16G NHP Svr
Overview
HPE ProLiant MicroServer Gen10 Plus v2
HPE ProLiant MicroServer Gen10 Plus v2 delivers an affordable compact yet powerful entry-level server that you can customize for on-premises, hybrid cloud, or even workloads demanding data center performance. It has the same design as the previous version and can be placed flat or vertically depending on the customer's environment. The latest Intel Xeon® E and Pentium® supported processors deliver compute performance as well as security and remote management into the server with HPE iLO silicon root of trust. Along with other enhancements such as 4x 1GbE onboard NICs and USB 3.2 Gen2 Type-A, whether you want a general-purpose server, NAS or even a virtualization server, you will be surprised at how much you can get out of this small and affordable server.
| Product Name |
HPE Microsvr G10+ V2 E-2314 16G NHP Server |
| Manufacturer Part Number |
P54649-001 |
| Product Type |
Server |
| Processor Core |
Quad-core (4 Core) |
| Environmentally Friendly |
Yes |
| Processor Manufacturer |
Intel |
| Redundant Power Supply |
No |
| Number of Total Memory Slots |
2 |
| Optical Drive Type |
No |
| Number of Processors Supported |
1 |
| Number of Processors Installed |
1 |
| Total Hard Drive Capacity |
No |
| Ethernet Technology |
Gigabit Ethernet |
| Maximum Power Supply Wattage |
180 W |
| Product Family |
ProLiant MicroServer Gen10 Plus v2 |
| Limited Warranty Duration |
1 Year |
| Processor Model |
E-2314 |
| Memory Technology |
DDR4 SDRAM |
| Operating System |
No |
| Chipset |
Intel C252 |
| Form Factor |
Ultra Micro Tower |
| Processor Speed |
2.80 GHz |
| Processor Type |
Xeon |
| Controller Type |
Serial ATA |
| Maximum Memory Supported |
64 GB |
| Standard Memory |
16 GB |
| Cache |
8 MB |
| Chipset Manufacturer |
Intel |
| Chipset Model |
C252 |
| Number of Power Supplies Supported |
1 |
| Number of Power Supplies Installed |
1 |
| Number of Total Expansion Bays |
4 |
| Number of 3.5" Bays |
4 |
| Number of Total Expansion Slots |
1 |
| VGA |
Yes |
| Number of Network (RJ-45) Ports |
4 |
| Network (RJ-45) |
Yes |
| DisplayPort |
Yes |
| Total Number of USB Ports |
7 |
| Number of USB 2.0 Ports |
1 |
| Number of Occupied Memory Slots |
1 |
| Hot Swappable Bays |
No |
| Controller Model |
VROC |
| Number of LFF Bays |
4 |
| PCI Express Details |
1 standard (Low Profile) PCIe 4.0 |
| Height |
4.7" |
| Width |
9.7" |
| Depth |
9.7" |
| Product Series |
MicroServer Gen10 Plus v2 |
| Plug / Connector Type |
C5 |
| Error Checking |
ECC |
| Input Voltage |
120 V AC
230 V AC
|
| Signal Processing |
Unregistered (Unbuffered) |
| Limited Warranty |
1 Year |
| Number of VGA Ports |
1 |
| Number of DisplayPorts |
1 |
| Manufacturer |
HPE |
| Manuf Part# |
P54649-001 |
