HPE Proliant P20248-B21 DL380 Gen10 Xeon-G 5220 18-Core 32GB 8SFF P408i-A

New

HPE Proliant P20248-B21 DL380 Gen10 Xeon-G 5220...

×




  • New

Detailed Specifications

HPE P20248-B21

ProLiant P20248‑B21 DL380 Gen10 Server – Intel Xeon Gold 5220 (18‑Core), 32 GB, 8 SFF Bays, P408i‑a RAID

The HPE ProLiant P20248‑B21 DL380 Gen10 is a versatile, single-socket 2U server equipped with an 18-core Intel Xeon Gold 5220 CPU, 32 GB ECC RAM, and a P408i‑a RAID controller. The NC (Networking Choice) option enables network customization with onboard Gigabit or optional 10/25 GbE adapters. Embedded HPE iLO 5 provides remote deployment, firmware updates, and proactive health monitoring.

Features

With eight front-access hot-plug SFF bays and expansion capabilities, it's well-suited for SMB to enterprise workloads like virtualization, databases, and data analytics.

Advanced Options

Built upon Intel’s Scalable Xeon architecture, this DL380 Gen10 model offers high core density and Turbo Boost for balanced compute performance. Its modular chassis supports up to 30 SFF drives (front + rear), allowing flexible storage configurations.

Product Key Features

    •  Intel Xeon Gold 5220 processor – 18 cores at 2.2 GHz (Turbo up to 3.9 GHz)

    •  32 GB DDR4 ECC Registered memory (1×32 GB, expandable to 3 TB)

    •  8 × 2.5″ SFF hot-plug drive bays (front), with chassis supporting up to 24‑30 SFF bays

    •  HPE Smart Array P408i‑a RAID controller – 12 Gb/s SAS with 2 GB cache

    •  NC (Networking Choice) with onboard Gigabit or optional 10/25 GbE adapter

    •  800 W Platinum hot-plug PSU (redundant-capable) & rack-ready 2U chassis

Reliability & Performance

This server delivers enterprise-grade reliability: ECC memory protects against data corruption, hot-swappable cooling, power, and storage components ensure continuous operation, and the P408i‑a RAID controller offers performance with redundancy. Supporting up to 3 TB of memory and optional NVIDIA GPUs or persistent memory modules, it's adaptable for compute-heavy and data-intensive tasks. Security features like silicon root-of-trust and iLO 5 harden the platform’s firmware and management interfaces.

Key Features :

  • Intel Xeon Gold 5220 (18 cores, 2.2 GHz base, 3.9 GHz max)

  • 32 GB DDR4 ECC Registered RAM (expandable to 3 TB)

  • 8 × SFF (2.5″) hot-plug front bays; up to 30 SFF total

  • HPE Smart Array P408i‑a (2 GB cache, 12 Gb/s SAS)

  • Networking Choice: onboard GbE or optional 10/25 GbE

  • 800 W Platinum hot-plug PSU (redundancy supported)

  • 3 × PCIe Gen3 slots (supports expansion adapters)

  • 2U rackmount with rail kit and cable management arm

  • HPE iLO 5 remote management & security features

SpecificationDetails
Model Number P20248‑B21
Server Type 2U Rackmount Server
Processor Intel Xeon Gold 5220 – 18 cores / 36 threads, 2.2 GHz base, 3.9 GHz Turbo
Processor Socket FCLGA3647; supports up to 2 CPUs (1 installed)
Memory 32 GB DDR4 ECC Registered RDIMM (1×32 GB); up to 3 TB across 24 slots
Drive Bays 8× SFF front; chassis expandable to 24–30 SFF
RAID Controller HPE Smart Array P408i‑a (2 GB cache, 12 Gb/s SAS)
Networking NC model: onboard GbE (Intel I350) or optional 10/25 GbE adapter
Power Supply 800 W Platinum hot-plug (RAID), redundancy capable
Expansion Slots 3 × PCIe Gen3; up to 8 total in dual-CPU setups
Management HPE iLO 5 (embedded), Intelligent Provisioning, remote admin tools
Security Features Silicon Root-of-Trust, Secure Boot, TPM support
Form Factor 2U rackmount; includes rail kit & cable management arm
Dimensions (H×W×D) ~3.4″ × 17.5″ × 28.7″ (87×445×729 mm)
Weight ~54 lb (24.5 kg)
Power Input 110–240 VAC, supports universal feeds
Operating Temp 0–40 °C (standard datacenter)
