StarTech POESLT1G48V 90W Industrial Gigabit PoE Splitter 48V View larger

StarTech POESLT1G48V 90W Industrial Gigabit PoE Splitter 48V

POESLT1G48V

New

In Stock

90W industrial PoE splitter 48V
×




$135.08

Detailed Specifications

StarTech POESLT1G48V – 90W Industrial Gigabit PoE Splitter 48V

Overview :

The StarTech POESLT1G48V is an industrial PoE splitter designed to convert a single PoE input into separate Gigabit data and DC power outputs, enabling deployment of non-PoE devices in locations without direct power access.

It supports up to 90W PoE input (IEEE 802.3af/at/bt) and provides configurable 12V, 16V, 24V, or 48V DC output via DIP switches. This flexibility allows integration with industrial controllers, sensors, telecom devices, and edge equipment.

Built for harsh environments, it features an IP30-rated enclosure, wide operating temperature range, and DIN rail or wall mounting options. Ideal for industrial automation, surveillance, and remote networking. Not suitable for low-power office PoE use cases where ruggedization is unnecessary.

Key Features :

  • Splits PoE into Gigabit data and DC output
  • Supports up to 90W IEEE 802.3bt input
  • Configurable 12–48V DC via DIP switches
  • Industrial IP30-rated rugged enclosure
  • DIN rail and wall mount installation

Technical Specifications

SpecificationDetails
Brand StarTech
Part Number POESLT1G48V
Product Type PoE Splitter
PoE Input IEEE 802.3af/at/bt (up to 90W)
Output Voltage 12V / 16V / 24V / 48V DC
Output Current Up to 1.5A
Data Interface 1 × RJ45 Gigabit Ethernet
Power Output 1 × Terminal Block
Max Distance 328 ft (100 m)
Mounting DIN Rail / Wall Mount
Enclosure Rating IP30
Operating Temperature -40°C to 75°C
Certifications CE, FCC, UL, RoHS
Product Length (inches) 4.1
Product Width (inches) 3.2
Product Height (inches) 1.3
Weight (lbs) 0.33
