APC AP9566 Rack Mount PDU View larger

APC AP9566 Rack Mount PDU, Basic 208V/20A, 12 Outlets, 1U Horizontal

New

In Stock

APC AP9566 1U Rack PDU, 16A, 208V, 12x C13
×




$179.00

  • New

Detailed Specifications

APC AP9566 – Rack PDU, Basic, 1U, 16A, 208V, 12x C13

Overview :

The APC AP9566 is a 1U rack-mounted Power Distribution Unit (PDU) designed for IT professionals requiring reliable power distribution in data centers or server rooms. It features 12 IEC 60320 C13 outlets and supports a maximum input current of 16A at 208V, delivering up to 3.328 kVA of power. This PDU is suitable for standard 19-inch EIA-310 racks, offering both horizontal and vertical mounting options. It includes a 12-foot NEMA L6-20P power cord and is UL and cUL listed for safety compliance.

Key Features :

  • 12 IEC 60320 C13 outlets

  • Supports up to 16A at 208V

  • Includes 12-foot NEMA L6-20P power cord

  • UL and cUL listed for safety

Specifications :

SpecificationDetails
Brand APC by Schneider Electric
Part Number AP9566
Product Type Rack PDU, Basic
Rack Units 1U
Mounting Orientation Horizontal / Vertical
Input Voltage 208V
Input Current 16A
Maximum Load Capacity 3.328 kVA
Input Connector NEMA L6-20P
Output Connectors 12 x IEC 60320 C13
Cord Length 12 feet (3.66 meters)
Operating Temperature 0°C to 45°C
Operating Humidity 0% to 95% RH
Certifications UL 60950, cUL listed
