APC AP6009A Basic Rack PDU View larger

APC AP6009A Basic Rack PDU

AP6009A

New

In Stock

Vertical Zero-U 220-240 V, 32 A basic rack PDU with 20 C13 + 6 C19 outlets for efficient equipment
×




$675.00

Detailed Specifications

APC AP6009A Basic Rack PDU

Overview :

The APC AP6009A Basic Rack Power Distribution Unit (PDU) is designed for efficient, reliable power delivery in rack-mount environments. With a vertical “Zero-U” form factor, it mounts alongside rack equipment without occupying valuable rack units. Operating at 220-240 V and supporting up to 32 A of load, this PDU features 20 × IEC C13 outlets and 6 × IEC C19 outlets—offering broad connectivity for servers, switches, and networking gear.

Built with cost-effective simplicity in mind, the AP6009A is ideal for data centers, wiring closets, and edge racks where dependable power distribution is key but advanced features like monitoring or switching are not required. Its compact profile, efficient installation design, and industry-standard input/output configuration make it a solid choice for delivering facility power into critical rack loads.

Key Features :

  • Zero-U vertical rack-mount design preserves rack unit space

  • Supports 220-240 V input at up to 32 A for high-capacity distribution

  • 20 IEC C13 outlets + 6 IEC C19 outlets for flexible equipment connectivity

  • Tool-less mounting kit included for fast installation

  • Economical yet reliable rack power distribution solution

Specifications :

AttributeSpecification
Brand APC by Schneider Electric
Part Number AP6009A
Product Type Basic Rack PDU
Compatibility Standard rack-mount equipment / NetShelter series
Input Voltage / Power 220-240 V AC, Maximum 32 A
Output Voltage / Power 220-240 V AC, approx. 7.7 kVA (7 700 VA)
Outlet Configuration 20 × IEC 60320 C13 + 6 × IEC 60320 C19
Dimensions (H×W×D) 64.02 in × 2.20 in × 1.69 in (≈ 1626 mm × 56 mm × 43 mm)
Weight 13.62 lb (≈ 6.18 kg)
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Humidity Range 5% – 95% RH (non-condensing)
Warranty 2-year limited repair or replace
Certifications CE, EAC, IRAM, VDE, RoHS compliant
Mounting Type / Form Factor Vertical Zero-U rack-mount
Power Cord Type IEC 60309 32A plug
Frequency 50/60 Hz
Primary Use Case Affordable rack power distribution in data centers
