Detailed Specifications
APC AP9547 - Network Management Card for Easy UPS 3 Series
Overview :
The APC AP9547 is a Network Management Card designed for the Easy UPS 3 Series, enabling secure remote monitoring and control of UPS units. It supports web browser access, EcoStruxure' IT Software, and SNMP-enabled systems. This card is pre-installed in all new Easy UPS 3S Pro, Easy UPS 3M, Easy UPS 3L, and Galaxy 3L models, and can be retrofitted into compatible units. It is suitable for deployment in data centers, server rooms, and industrial environments.
Key Features :
Gigabit Ethernet connectivity for fast data transfer
Supports simultaneous access via web UI, CLI, and serial port
Includes 12-month Secure NMC Subscription for firmware updates
Compliant with IEC 62443-4-2 cybersecurity standards
Specifications :
| Attribute | Specification |
|---|
| Brand | APC by Schneider Electric |
| Part Number | AP9547 |
| Product Type | Network Management Card (NMC3) |
| Supported UPS Models | Easy UPS 3S, Easy UPS 3S Pro, Easy UPS 3M, Easy UPS 3L, Galaxy 3L, Galaxy PW 2nd Gen |
| Mounting | Not rack-mountable |
| Network Ports | 1 x RJ-45 (10/100/1000Base-T) |
| USB Ports | 1 x Micro-USB (for console access) |
| Serial Ports | 1 x DB9 (for serial communication) |
| Dimensions (HxWxD) | 44 mm x 52 mm x 80 mm |
| Weight | 50 g |
| Operating Temperature | -5°C to 45°C |
| Storage Temperature | -15°C to 65°C |
| Humidity Range | 0% to 95% (non-condensing) |
| Certifications | RoHS, China RoHS, CISPR 32, EN 55024, EN 61000 series, FCC Class A, ICES-003, VCCI Class A |
