StarTech P2DD46A2-KVM-SWITCH 2 Port Dual DisplayPort KVM Switch View larger

StarTech P2DD46A2-KVM-SWITCH 2 Port Dual DisplayPort KVM Switch

P2DD46A2-KVM-SWITCH

New

2‑port dual‑DisplayPort 4K60 KVM switch
×




Detailed Specifications

StarTech  P2DD46A2-KVM-SWITCH 2 Port Dual DisplayPort KVM Switch

overview

The StarTech P2DD46A2‑KVM‑SWITCH is a 2‑port dual‑monitor DisplayPort KVM switch that lets a single console (dual DisplayPort monitors plus keyboard, mouse and USB peripherals) control two DisplayPort‑equipped systems. It supports 4K @ 60 Hz (3840×2160) video on both monitors and shares USB devices using integrated USB 3.2 Gen 1 (5 Gbps) hub ports plus dedicated USB 2.0 HID ports for keyboard and mouse. The switch includes push‑button and hotkey switching with LED indicators and audible confirmation for reliable host selection. It’s ideal for engineering desks, control rooms, and multi‑system workstations needing high‑resolution dual‑display control. NOT suitable for multi‑user/matrix KVM deployments or applications requiring more than two hosts.

key features

  • supports dual 4K @ 60 Hz DisplayPort video per host
  • USB 3.2 Gen 1 (5 Gbps) hub ports for shared devices
  • USB 2.0 dedicated HID ports for keyboard/mouse
  • hotkey & push‑button host switching with audio/LED feedback
  • supports audio via 3.5 mm console connections

specifications

SpecificationDetail
Brand StarTech.com
Part Number P2DD46A2‑KVM‑SWITCH
Product Type 2‑port dual‑DisplayPort KVM switch
Supported Hosts 2 computers
Video Interface DisplayPort 1.2
Max Resolution 3840 × 2160 @ 60 Hz
USB Hub Ports 2 × USB 3.2 Gen 1 (5 Gbps)
HID Ports 2 × USB 2.0 (keyboard/mouse)
Audio 3.5 mm stereo in/out
Switching Methods Push‑button, hotkey
Indicators LEDs, audible buzzer
Form Factor Desktop
Compliance TAA, RoHS, CE
Power External DC adapter 100‑240 VAC
Operating Temp 0 °C – 40 °C
ESD Protection Yes (level‑3)
