HPE Q0U61A Fibre Channel Switch SN6600B Power Pack+ 48-Port 32Gb

Q0U61A

New

High-performance 48-port 32Gb

×




Detailed Specifications

HPE Q0U61A

SN6600B Power Pack+ 48-Port 32Gb Fibre Channel Switch

The HPE Q0U61A SN6600B Power Pack+ is a high-density, enterprise-class Fibre Channel Switch designed to meet the demanding requirements of modern data centers. With 48 active 32Gb SFP+ ports and 4 QSFP+ ports, it offers scalable performance and flexibility for storage area networks (SANs). The switch delivers an aggregate bandwidth of approximately 2 Tbps and boasts ultra-low latency of around 700 nanoseconds, ensuring rapid data access and minimal bottlenecks

Features

This 1U rack-mountable switch is engineered for high availability and reliability, featuring redundant, hot-swappable power supplies and cooling fans. It supports advanced SAN management capabilities through HPE Power Pack+ software, which includes features like Fabric Vision, ISL Trunking, and Extended Fabric. The SN6600B is backward compatible with 4/8/16/32 Gb Fibre Channel speeds, providing investment protection and future-proofing for evolving storage needs.

Advanced Options

The HPE Q0U61A SN6600B switch is built to deliver exceptional performance and reliability in enterprise SAN environments. Its high-density port configuration allows for efficient space utilization, while the 1U form factor ensures compatibility with standard data center racks.

Product Key Features

  • 48 x 32Gb SFP+ Fibre Channel ports

  • 4 x QSFP+ ports (each supporting 4 x 32Gb breakout)

  • Aggregate bandwidth of approximately 2 Tbps

  • Ultra-low port-to-port latency (~700 ns)

  • 1U rack-mountable form factor

  • Redundant, hot-swappable power supplies and cooling fans

  • Supports HPE Power Pack+ SAN management software

  • Backward compatibility with 4/8/16/32 Gb Fibre Channel speeds

  • Advanced SAN features: ISL Trunking, Extended Fabric, Fabric Vision

  • Maximum frame size: 2112 bytes

Reliability & Performance

The switch's low latency and high throughput capabilities make it suitable for latency-sensitive applications and large-scale data transfers. Additionally, the inclusion of redundant power supplies and cooling fans ensures continuous operation and minimizes the risk of downtime.

Key Features :

  • 48 x 32Gb SFP+ Fibre Channel ports

  • 4 x QSFP+ ports (each supporting 4 x 32Gb breakout)

  • Aggregate bandwidth of approximately 2 Tbps

  • Ultra-low port-to-port latency (~700 ns)

  • 1U rack-mountable form factor

  • Redundant, hot-swappable power supplies and cooling fans

  • Supports HPE Power Pack+ SAN management software

  • Backward compatibility with 4/8/16/32 Gb Fibre Channel speeds

  • Advanced SAN features: ISL Trunking, Extended Fabric, Fabric Vision

  • Maximum frame size: 2112 bytes

SpecificationDetails
Model Number Q0U61A
Type Fibre Channel Switch
Ports 48 x 32Gb SFP+, 4 x QSFP+
Form Factor 1U Rack-mountable
Aggregate Bandwidth ~2 Tbps
Latency ~700 ns
Power Supplies Redundant, hot-swappable
Cooling Fans Redundant, hot-swappable
Software HPE Power Pack+ SAN management
Compatibility Backward compatible with 4/8/16/32 Gb FC speeds
