Detailed Specifications
HPE P55252-B21 DL385 G10+ V2 7313 MR416I-A 8SFF Server
Overview :
The HPE ProLiant DL385 Gen10 Plus v2 Server is redefining price/performance with the new math for virtualized compute. Powered by the latest AMD® EPYC® 7003 Series Processors , the HPE ProLiant DL385 Gen10 Plus v2 Server offers greater processing power, memory speeds up to 3200 MT/s. and data transfer rates with PCIe Gen4 capabilities.
This 2P, 2U server has been designed with flexibility while delivering a high core count and large memory footprint. Choose this purpose-built platform for virtualization, High Performance Compute and memory centric workloads.
Specifications :
| Processor |
|---|
| Processor cache |
128 MB |
| Processor frequency |
3 GHz |
| Number of processors installed |
1 |
| Processor model |
7313 |
| Processor boost frequency |
3.7 GHz |
| Processor cores |
16 |
| Processor manufacturer |
AMD |
| Motherboard chipset |
AMD SoC |
| Maximum number of SMP processors |
2 |
| Processor family |
AMD EPYC |
| Memory |
|---|
| Internal memory |
32 GB |
| Memory layout (slots x size) |
1 x 32 GB |
| Memory slots |
32x DIMM |
| Memory clock speed |
3200 MHz |
| Maximum internal memory |
8192 GB |
| Internal memory type |
DDR4-SDRAM |
| ECC |
Yes |
| Storage |
|---|
| Supported HDD sizes |
2.5" |
| RAID support |
Yes |
| RAID levels |
0, 1, 5, 6, 10, 50, 60 |
| Optical drive type |
No |
| Number of HDDs supported |
8 |
| Maximum storage capacity |
67.2 TB |
| Hot-Plug support |
Yes |
| HDD interface |
SATA, Serial Attached SCSI (SAS) |
| Graphics |
|---|
| Maximum graphics card memory |
16 MB |
| On-board graphics card |
Yes |
| Network |
|---|
| LAN controller |
Broadcom 57416 |
| Ethernet LAN |
Yes |
| Ethernet interface type |
10 Gigabit Ethernet |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| VGA (D-Sub) ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| Optical drive |
|---|
| Optical drive type |
No |
| Design |
|---|
| Rack mounting |
Yes |
| Optical drive type |
No |
| Chassis type |
Rack (2U) |
| Performance |
|---|
| Compatible operating systems |
Windows Server 2016 Windows Server 2019 (Most Recent Version) VMware ESXi 6.7 U3 VMware ESXi 7.0 U1/U2 SUSE Linux Enterprise Server (SLES) 12 SP5 SUSE Linux Enterprise Server (SLES) 15 SP2 Red Hat Enterprise Linux (RHEL) 8.3 Citrix Hypervisor 8.2 Ubuntu 20.04 LTS |
| Remote administration |
iLO 5 ASIC |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Operating system installed |
No |
| Harmonized System (HS) code |
84714100 |
| Software |
|---|
| Compatible operating systems |
Windows Server 2016 Windows Server 2019 (Most Recent Version) VMware ESXi 6.7 U3 VMware ESXi 7.0 U1/U2 SUSE Linux Enterprise Server (SLES) 12 SP5 SUSE Linux Enterprise Server (SLES) 15 SP2 Red Hat Enterprise Linux (RHEL) 8.3 Citrix Hypervisor 8.2 Ubuntu 20.04 LTS |
| Operating system installed |
No |
| Power |
|---|
| Redundant power supply (RPS) support |
Yes |
| Power supply |
800 W |
| Management features |
|---|
| Remote administration |
iLO 5 ASIC |
