| Design |
|---|
| Colour name |
Thunder Black |
| Product Type |
Notebook |
| Form factor |
Clamshell |
| Product colour |
Black |
| Display |
|---|
| HD type |
WUXGA |
| Panel type |
IPS |
| LED backlight |
Yes |
| Display brightness |
300 cd/m² |
| Contrast ratio (typical) |
800:1 |
| Touchscreen |
Yes |
| Display resolution |
1920 x 1200 pixels |
| Display diagonal |
16" |
| Anti-glare screen |
Yes |
| RGB colour space |
NTSC |
| Colour gamut |
45% |
| Native aspect ratio |
16:10 |
| Processor |
|---|
| Processor cache |
16 MB |
| Processor frequency |
2.9 GHz |
| Processor model |
6650U |
| Processor boost frequency |
4.5 GHz |
| Processor cores |
6 |
| Motherboard chipset |
AMD SoC |
| Processor manufacturer |
AMD |
| Processor family |
AMD Ryzen™ 5 PRO |
| Memory |
|---|
| Memory form factor |
On-board |
| Internal memory |
16 GB |
| Internal memory type |
LPDDR5-SDRAM |
| Memory clock speed |
6400 MHz |
| Maximum internal memory |
16 GB |
| Memory channels |
Dual-channel |
| Storage |
|---|
| SSD form factor |
M.2 |
| Storage media |
SSD |
| Optical drive type |
No |
| Number of SSDs installed |
1 |
| SSD capacity |
256 GB |
| SSD interface |
PCI Express 4.0 |
| Card reader integrated |
No |
| Total storage capacity |
256 GB |
| Total SSDs capacity |
256 GB |
| NVMe |
Yes |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| On-board graphics card model |
AMD Radeon 660M |
| Discrete graphics card model |
Not available |
| Audio |
|---|
| Audio chip |
Realtek ALC3287 |
| Number of microphones |
2 |
| Audio system |
Dolby Audio |
| Number of built-in speakers |
2 |
| Speaker power |
2 W |
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera resolution |
1920 x 1080 pixels |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Front camera HD type |
Full HD |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| WLAN controller model |
Qualcomm NFA725A |
| Near Field Communication (NFC) |
No |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
5.1 |
| WWAN |
Not installed |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Qualcomm |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Sleep-and-Charge ports |
1 |
| USB Sleep-and-Charge |
Yes |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| USB Power Delivery |
Yes |
| Keyboard |
|---|
| Pointing device |
ThinkPad UltraNav |
| Numeric keypad |
Yes |
| Spill-resistant keyboard |
Yes |
| Keyboard backlit |
Yes |
| Keyboard language |
English |
| Software |
|---|
| Operating system language |
English |
| Operating system installed |
Windows 11 Pro |
| Technical details |
|---|
| Form factor |
Clamshell |
| Product colour |
Black |
| Sustainability certificates |
RoHS, TCO, ENERGY STAR, EPEAT Gold |
| Battery |
|---|
| Battery technology |
Lithium Polymer (LiPo) |
| Battery capacity |
52.5 Wh |
| Fast charging |
Yes |
| Power |
|---|
| AC adapter power |
65 W |
| AC adapter frequency |
50/60 Hz |
| AC adapter input voltage |
100 - 240 V |
| Security |
|---|
| Password protection |
Yes |
| Cable lock slot type |
Kensington |
| Trusted Platform Module (TPM) |
Yes |
| Password protection type |
BIOS, Power on, SSD, Supervisor |
| Fingerprint reader |
Yes |
| Cable lock slot |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Maximum shipping altitude |
120000" (3048 m) |
| Certificates |
|---|
| Certification |
ErP Lot 3 MIL-STD-810H |
| Sustainability |
|---|
| Sustainability certificates |
RoHS, TCO, ENERGY STAR, EPEAT Gold |
| Weight & dimensions |
|---|
| Width |
14.2" (361.9 mm) |
| Depth |
10.1" (255.5 mm) |
| Height |
0.807" (20.5 mm) |
| Weight |
3.99 lbs (1.81 kg) |
| Other features |
|---|
| WLAN controller model |
Qualcomm NFA725A |
| On-board graphics card |
Yes |
| Audio system |
Dolby Audio |
| Maximum shipping altitude |
120000" (3048 m) |
| Anti-glare screen |
Yes |
