Detailed Specifications
TP-Link TL-SG1048 48 Port Gigabit Ethernet Switch Plug and Play
Overview :
The TL-SG1048 Unmanaged Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to boost your old network to 1000Mbps. Increase the speed of your network server and backbone connections make Gigabit a reality. Power users in the home, office, workgroup or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files and other applications that have to move large files across the network almost instantly.
Features :
- One Switch Made to Expand Network: 48� 10/100/1000Mbps RJ45 Ports supporting Auto Negotiation and Auto MDI/MDIX.
- Gigabit that Saves Energy: Latest innovative energy-efficient technology greatly expands your network capacity with much less power consumption and helps save money.
- Reliable and Quiet: IEEE 802.3X flow control provides reliable data transfer and Fanless design ensures quiet operation.
- Plug and Play: Easy setup with no software installation or configuration needed.
- Advanced Software Features: TL-SG1048 features non-blocking wire-speed architecture with a 96Gbps switching capacity for maximum data throughput. An 8K MAC address table provides scalability for even the largest networks.
Specifications :
| Product Name |
48-Port Gigabit Switch |
| Product Type |
Ethernet Switch |
| Manageable |
No |
| Ethernet Technology |
Gigabit Ethernet
Fast Ethernet
|
| Media Type Supported |
Twisted Pair |
| Total Number of Network Ports |
48 |
| Form Factor |
Rack-mountable
Desktop
|
| Power Consumption |
32.30 W |
| Power Source |
Power Supply |
| Layer Supported |
2 |
| Environmentally Friendly |
Yes |
| Network (RJ-45) |
Yes |
| Port / Expansion Slot Details |
48 x Gigabit Ethernet Network |
| Networking Standards |
IEEE 802.3i
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3x
|
| Height |
1.7" |
| Width |
17.3" |
| Depth |
14.2" |
| Product Model |
TL-SG1048 |
| Network Technology |
10/100/1000Base-T |
| Package Contents |
- TL-SG1048 48-Port Gigabit Switch
- Power Cord
- Installation Guide
- Rackmount Kits
- Rubber Feet
|
| Limited Warranty |
3 Year |
| Number of Network (RJ-45) Ports |
48 |
| Frequency |
50 Hz
60 Hz
|
