Detailed Specifications
TP-Link TL-SG105E 5 Port Gigabit Switch Easy Smart Managed Plug & Play
Overview :
What This Product Does
The TL-SG105E 5-Port Gigabit Easy Smart switch is an ideal upgrade from an unmanaged switch, designed for Small and Medium Business networks that require simple network management. Network administrators can effectively monitor traffic via Port Mirroring, Loop Prevention and Cable Diagnostics features. To optimize traffic on your business network, TL-SG105E offers both port and tag based QoS to keep latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, the TL-SG105E can save up to 75% of power consumption, making it an eco-friendly solution for your business network.
Features :
- 5-Gigabit ports provide instant large file transfers
- 15K jumbo frame improves performance of large data transfers
- Effective network monitoring via port mirroring, loop prevention and cable Diagnostics
- Abundant VLAN features improve network security via traffic segmentation
- Igmp snooping optimizes multicast applications
- Port and tag-based QoS enable smooth latency-sensitive traffic
- System Ram Type: ddr3_sdram
Specifications :
| Product Name |
5-Port Gigabit Easy Smart Switch |
| Product Type |
Ethernet Switch |
| Manageable |
Yes |
| Ethernet Technology |
Gigabit Ethernet |
| Product Family |
EasySmart |
| Stack Port |
No |
| Media Type Supported |
Twisted Pair |
| Total Number of Network Ports |
5 |
| PoE (RJ-45) Port |
No |
| Form Factor |
Desktop |
| Power Consumption |
2.70 W |
| Power Source |
Power Adapter |
| Layer Supported |
2 |
| Environmentally Friendly |
Yes |
| Network (RJ-45) |
Yes |
| Modular |
No |
| Uplink Port |
No |
| Port / Expansion Slot Details |
5 x Gigabit Ethernet Network |
| Product Material |
Metal |
| Country of Origin |
China |
| Height |
1" |
| Width |
3.9" |
| Depth |
3.9" |
| Product Model |
TL-SG105E |
| Network Technology |
10/100/1000Base-T |
| Product Line |
EasySmart |
| Limited Warranty |
3 Year |
| Twisted Pair Cable Standard |
Category 6 |
| Token Ring Port |
No |
| LRE Port |
No |
| USB |
No |
| Number of Network (RJ-45) Ports |
5 |
| Management Port |
No |
| Bypass |
No |
