Detailed Specifications
StarTech.com ET91000LCOAM OAM Gigabit Ethernet Converter
OVERVIEW:
The ET91000LCOAM Managed Fiber Media Converter lets you extend a Gigabit Ethernet connection over Multimode LC fiber, with the added benefit of remote management capabilities.
Compliant with 802.3ah OAM (Operations, Administration & Management), this managed media converter incorporates an easy-to-use web interface for operation, administration, and maintenance, enabling you to quickly determine the location of failing links and the fault conditions without sending service personnel to the physical location of the device.
An effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the Ethernet to fiber converter supports full Gigabit speeds at distances of up to 550m (1804ft) through the installed Multi-Mode LC SFP. The converter also features an all-steel chassis, for durability in harsh environments.
For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis(ETCHS2U), as well as a replaceable MSA-compliant SFP slot.
About this item
- ETHERNET OVER FIBER EXTENSION: Use this full duplex converter to convert and extend a Gigabit Ethernet connection over multimode LC fiber (up to 550m / 1804ft) with remote management capabilities.
- INCLUDES SFP: For added convenience, this IT-grade network fiber media converter includes an SFP transceiver, enabling an 850nm LC multimode Gigabit fiber connection.
- PLUG AND PLAY: Designed for ease of use, this LC RJ45 copper to fiber media converter provides a quick and easy setup. It can be used as a standalone device or mounted to a wall.
Specifications:
| Product Name |
OAM Managed Gigabit Ethernet Fiber Media Converter MM LC 550m |
| Manufacturer Part Number |
ET91000LCOAM |
| Product Type |
Transceiver/Media Converter |
| Ethernet Technology |
Gigabit Ethernet |
| USB |
No |
| DVI |
No |
| Number of Network (RJ-45) Ports |
1 |
| Network (RJ-45) |
Yes |
| Number of LC Ports |
1 |
| Media Type Supported |
Twisted Pair
Optical Fiber
|
| Fiber Mode Supported |
Multi-mode |
| Total Number of Ports |
2 |
| LC Port Type |
Duplex |
| TAA Compliant |
Yes |
| Form Factor |
External |
| Network Technology |
10/100/1000Base-T
1000Base-LX/SX
|
| Maximum Distance Supported |
1804.46 ft |
| Power Source |
AC Adapter |
| Environmentally Friendly |
Yes |
| Management Port |
No |
| Fiber Optic Wavelength |
850 nm |
| Country of Origin |
Taiwan |
| Height |
0.9" |
| Width |
3.4" |
| Depth |
6.4" |
| Plug / Connector Type |
Type M |
| Power Consumption |
12 W |
| Packaged Quantity |
1 |
| Parallel Port |
No |
| Digital Audio |
No |
| Digital Audio / Video |
No |
| Product Color |
Black |
| Compatibility |
StarTech 2U Rackmount Chassis (ETCHS2U) |
| Input Voltage |
12 V DC |
| Stock Details ET91000LCOAM |
| Manufacturer |
StarTech.com |
| Manuf Part# |
ET91000LCOAM |
