Detailed Specifications
Ruckus Wireless LLC ICX7450-24P-E2 24 Port 1 Gbe Switch PoE+ Bundle Inc 4X10G SFP+
Overview :
The Ruckus ICX7450-24P-E2 is a high-performance 24-port Gigabit Ethernet switch, offering an innovative and feature-rich solution for networking needs. With Power over Ethernet Plus (PoE+) capability, this switch not only facilitates high-speed data connectivity but also provides power to compatible devices, eliminating the need for separate power sources. This feature is particularly advantageous in environments where deploying and managing power sources for individual devices is impractical.
Designed for versatility, the switch includes four 10 Gigabit SFP+ ports, offering flexible options for high-speed uplinks or connectivity to other network devices. The inclusion of SFP+ ports enhances the overall bandwidth and throughput of the network, ensuring seamless data transfer for demanding applications.
Ideal for various deployment scenarios, the ICX7450-24P-E2 excels in delivering reliable and efficient network performance. Whether in office environments, educational institutions, or other business settings, the switch provides a robust foundation for connecting a multitude of devices while ensuring power delivery to connected PoE+ devices.
Moreover, with Ruckus's commitment to cutting-edge technology and network solutions, the ICX7450-24P-E2 embodies reliability and innovation, making it a standout choice for those seeking a powerful, feature-packed switch to meet the demands of modern networking. Whether supporting VoIP phones, surveillance cameras, or other PoE-enabled devices, this switch offers a comprehensive and efficient networking solution for diverse applications.
Specifications :
| Subtype |
Gigabit Ethernet |
| Ports |
16 x 10/100/1000 (PoE+) + 8 x 10/100/1000 (PoH) + 4 x 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ |
| Power Over Ethernet (PoE) |
PoH |
| Performance |
Switching capacity: 288 Gbps ¦ Forwarding performance: 214 Mpps ¦ Aggregate stacking bandwidth: 960 Gbps ¦ VPN throughput (IPSec): 10 Gbps |
| Capacity |
Virtual interfaces (VLANs): 4096 ¦ Spanning Tree Protocol instances: 254 ¦ IPv4 routes: 15168 ¦ IPv6 routes: 5120 ¦ QoS hardware queues per port: 8 ¦ IPSec tunnels: 20 ¦ Hardware multicast groups: 8192 |
| MAC Address Table Size |
32768 entries |
| Jumbo Frame Support |
9216 bytes |
| Max Units In A Stack |
12 |
| Routing Protocol |
IGMPv2, IGMP, IGMPv3, MSDP, static IPv4 routing, static IPv6 routing, ECMP, MLDv2, MLD |
| Remote Management Protocol |
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, CLI |
| Encryption Algorithm |
AES, ECDSA, IKEv2 |
| Authentication Method |
RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
