Detailed Specifications
StarTech.com ST1000SPEX2 Add a 10/100/1000Mbps Ethernet port to any PC through a PCI Express slot - pci express gigabit network card - pci express gigabit lan card - pci express gigabit server adapter - PCIe gigabit nic - low profile pci express network card.
Overview ST1000SPEX2
The ST1000SPEX2 PCIe Gigabit Ethernet Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface.
Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging, and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter delivers rock-solid performance.
Plus, the card includes both full profile and low profile/half-height installation brackets for installation in a wide range of computer/server chassis, regardless of form factor.
The ST1000SPEX2 network card is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Specifications ST1000SPEX2
| Product Name |
1 Port PCIe Gigabit PCIe Network Card - NIC Adapter |
| Manufacturer Part Number |
ST1000SPEX2 |
| Product Type |
Gigabit Ethernet Card |
| Number of Network (RJ-45) Ports |
1 |
| Total Number of Ports |
1 |
| Form Factor |
Plug-in Card |
| Network Technology |
10/100/1000Base-T |
| Data Transfer Rate |
125 MB/s |
| Device Supported |
PC |
| Host Interface |
PCI Express x1 |
| Environmentally Friendly |
Yes |
| Chipset Manufacturer |
Realtek |
| Chipset Model |
RTL8111 |
| Media Type Supported |
Twisted Pair |
| Country of Origin |
China |
| Height |
0.7" |
| Width |
4.7" |
| Packaged Quantity |
1 |
| Limited Warranty |
2 Year |
| Card Height |
Full-height
Low-profile
|
| USB |
No |
| Network (RJ-45) |
Yes |
| Serial Port |
No |
| Ethernet AUI |
No |
| XJACK |
No |
| PoE (RJ-45) Port |
No |
| InfiniBand |
No |
| Length |
2.7" |
| System Requirements |
- Windows® 2000, XP, Vista, 7, 8, 8.1, 10
- Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
- Mac OS X® 10.6 to 10.9
- Linux 2.4.x to 4.11.x LTS Versions Only
|
| Manufacturer |
StarTech.com |
| Manuf Part# |
ST1000SPEX2 |
