APC SRT10KXLT Smart-UPS SRT 10000VA with Two 208/240V to 120V 5kVA

New

APC SRT10KXLT Smart-UPS SRT 10000VA with Two 208/240V to 120V 5kVA
×




  • New

Detailed Specifications

APC

SRT10KXLT

5KTF2 Smart‑UPS SRT 10 kVA/10 kW On‑Line UPS – Rugged Tower/Rack with Dual 5 kVA Voltage Transformers

The APC SRT10KXLT‑5KTF2 is a top-tier, double-conversion on-line UPS delivering 10 kVA (10 kW) of clean, continuous power. Designed for high-demand systems—such as servers, storage arrays, network infrastructure, medical labs, and industrial equipment—this unit ensures uninterrupted operation during faults, outages, or power-quality disturbances. It includes two integrated 5 kVA voltage step-down transformers, enabling simultaneous support for both 208/240 V and 120 V loads from the same UPS. The combination of a full-power UPS and dual transformer output makes this an adaptable, space-efficient power protection solution.

Features

The SRT10KXLT‑5KTF2 employs online double-conversion technology to regenerate power from the input, isolating sensitive equipment from voltage anomalies, surges, and frequency shifts. Its wide input range (100–275 V half-load, 208 V nominal) accommodates challenging electrical environments. The two 5 kVA built-in transformers automatically step down 208/240 V to 120 V, providing up to 10 kW across mixed-voltage outlets without external gear—a game-changer for combined equipment racks.

Advanced Options

This model includes a SmartSlot-enabled SNMP/Ethernet network card, USB/serial ports, and PowerChute software for remote management and safe shutdowns. Its stackable rack/tower chassis accepts additional battery packs to extend runtime, and its intuitive LCD panel provides real-time status, metrics, and alerts.

Product Key Features

  • Double-conversion on-line UPS: 10 kVA / 10 kW continuous output

  • Dual 5 kVA step-down transformers provide both 208/240 V and 120 V outputs

  • Integrated SmartSlot network management with remote monitoring

  • Rack/tower convertible design with included rail kit

  • Hot-swappable internal batteries with external runtime extension

  • Advanced features: automatic bypass, Green Mode energy-saving, environmental sensors

Reliability & Performance

This UPS ensures uninterrupted, clean power via automatic voltage regulation and full-time double-conversion. With zero transfer time during outages, it protects mission-critical systems reliably. The integrated step-down transformers eliminate the need for separate voltage converters and simplify rack configurations across mixed-voltage equipment. Its high-efficiency Green Mode minimizes energy loss during steady power conditions, while comprehensive battery management—including temperature compensation and scheduled self-tests—maximizes battery health. Network connectivity enables proactive alerts and remote system oversight. Engineered for industrial-grade reliability, this unit maintains performance in environments up to 40 °C and integrates easily into dense IT deployments.

Key Features (Bullet List)

  • 10 kVA / 10 kW on-line UPS protection

  • Dual 5 kVA transformers for both 208/240 V and 120 V outputs

  • SmartSlot-enabled network management card installed

  • USB, serial, and SmartSlot communication ports included

  • Rack/tower convertible (3U) with rail mounting

  • Hot-swappable batteries and scalable runtime

  • Dual bypass paths and environmental sensor support

  • Energy-saving Green Mode operation

  • Flash-upgradeable firmware

  • 3-year UPS / 2-year battery warranty

Specifications :

SpecificationDetails
Model Number SRT10KXLT‑5KTF2
Product Type Double-Conversion Online UPS w/ Dual Step-Down Transformers
Power Capacity 10 kVA / 10 kW
Input Voltage Range 100–275 V (half load), 208 V nominal
Output Voltage 208 V & stepped-down 120 V outputs
Transformers Two 5 kVA 208/240 → 120 V step-down units
Outlet Configuration Mixed 208 V and 120 V receptacles (counts vary by setup)
Topology Double-conversion on-line
Form Factor 3U Rack/Tower convertible with rails included
Communication Ports SmartSlot, RJ-45 (SNMP/Ethernet), USB, Serial
Display Multi-function LCD panel
Runtime Expansion Supports external battery packs
Efficiency Modes Normal & Eco (Green Mode)
Temperature Operating 0–40 °C
Certifications ENERGY STAR V2.0, UL 1778, FCC, RoHS
Dimensions (H×W×D) 17.01″ × 10.35″ × 28.15″ (432 × 263 × 715 mm)
Weight ~496 lb (225 kg)
Warranty 3-Year (UPS), 2-Year (batteries)
