Netgear AXM762-10000S ProSafe AXM762 - SFP+ transceiver module View larger
Previous Next

NETGEAR AXM762-10000S ProSafe SFP+ Transceiver Module

New

In Stock

Netgear SFP+ Transceiver, 10GBase-LR for Single Mode 9/125µm Fiber
×




$739.92

  • New

Detailed Specifications

NETGEAR AXM762-10000S

ProSafe SFP+ Transceiver Module – 10GBASE‑LR (1310 nm, SMF, LC Duplex, up to 10 km)

The NETGEAR AXM762‑10000S is a rugged, long-range SFP+ transceiver module that delivers reliable 10 Gbps fiber connectivity over distances up to 10 km. Ideal for enterprise, data center, campus, or service‑provider environments seeking high-bandwidth, single‑mode extensions. shorter runs on multimode (300 m on OM3; 33 m on OM1)

Features

This module integrates seamlessly into NETGEAR managed switches—including M5300, M7100, M7300 series, plus select Smart and ProSafe models—providing hot-pluggable 10 GbE fiber uplinks without disruption With built‑in DOM, users can monitor optical levels, temperature, and power to proactively maintain network health.

Advanced Options

Operating at 1310 nm with LC duplex connectors, it’s engineered for long-haul SMF links, ensuring high performance and flexibility. Built on the IEEE 802.3ae 10GBASE-LR specification, the AXM762 supports up to 10 km on 9/125 µm fiber and

Product Key Features

    •  10 Gigabit Ethernet over single-mode fiber (10GBASE-LR)

    •  LC duplex connector; hot-swappable SFP+ form factor

    •  Supports distances up to 10 km over 9/125 µm SMF

    •  Works with NETGEAR M/L-series switches, Smart & ProSafe series

    •  Operates across 0–70 °C; low power <1.5 W

    •  DOM support for real-time diagnostics

Reliability & Performance

Crafted for enterprise-grade environments, the AXM762 operates in temperatures from 0–70 °C and consumes less than 1.5 W, delivering energy-efficient 10 Gbps links . Thanks to its MSA-compliant SFP+ form, it allows hot-swappable installation—minimizing downtime during upgrades or replacementsWith a Mean Time Between Failures (MTBF) of ~5 million hours, this module ensures long-term network reliability .

Key Features (Bullet List)

  • 10 GBASE‑LR SFP+ transceiver for single-mode fiber

  • LC duplex connector, 1310 nm wavelength

  • Up to 10 km over 9/125 µm SMF; OM3 up to 300 m, OM1 up to 33 m

  • Hot-swappable, MSA-compliant SFP+ form factor

  • Digital Optical Monitoring (DOM) support

  • Operational temperature 0–70 °C; power consumption <1.5 W

SpecificationDetails
Model Number AXM762‑10000S
Product Type SFP+ Transceiver Module
Networking Standard IEEE 802.3ae 10GBASE‑LR
Max Data Rate 10 Gbps
Wavelength 1310 nm
Connector Type LC Duplex
Fiber Type Single‑Mode (9/125 µm); Multi-mode compatibility
Max Distance SMF: 10 km; OM3: 300 m; OM1: 33 m
DOM Yes
Power Consumption <1.5 W
Operating Temp 0 to 70 °C
Form Factor Hot-swappable SFP+ (MSA-compliant)
Dimensions ~2.19 × 0.53 × 0.46 in (55.7 × 13.7 × 11.9 mm)
Weight ~19 g
MTBF 4,986,536 hours
