Ruckus Wireless Unleash 9U1-T750-US51 T750SE 802.11AX OTDR Wireless Access Point

New

High-density outdoor Wi-Fi 6 AP with sector antenna

×




  • New

Detailed Specifications

Ruckus T750SE (9U1-T750-US51)

Outdoor Wi-Fi 6 Access Point with 120° Sector Antenna & Integrated OTDR

The Ruckus T750SE (model 9U1-T750-US51) is a ruggedized, dual-band Wi-Fi 6 (802.11ax) outdoor access point designed with a built-in 120° sector antenna and integrated OTDR fiber diagnostics. Engineered for high-density environments such as airports, stadiums, campuses, and public plazas, it combines superior performance, IoT readiness, and advanced backhaul flexibility for large-scale deployments.

Expanded Overview :

The R750SE operates on both 2.4GHz and 5GHz bands, each with 4×4:4 spatial streams, delivering aggregated throughput of approximately 3.548 Gbps (2.4 Gbps on 5GHz and 1.148 Gbps on 2.4GHz). Its integrated 120° sector antenna streamlines outdoor deployments with consistent, wide-area coverage, while optional support for external antennas expands deployment flexibility.

For robust backhaul and connectivity, the R750SE features multi-gigabit options including a 2.5GbE port, a 1GbE port, SFP fiber slot, GPS capability, and PoE in/out support. A key highlight is the built-in OTDR functionality, which enables real-time optical fiber diagnostics, reducing downtime and simplifying maintenance for telecom and service provider teams.

Designed for IoT convergence, the unit includes onboard BLE and Zigbee radios, along with support for pluggable IoT modules, to consolidate Wi-Fi and IoT networks onto a single platform. With MU-MIMO, OFDMA, and BeamFlex+ adaptive antenna technologies, it supports up to 1,024 simultaneous clients with maximum spectrum efficiency and responsiveness, even in ultra-dense device environments.

Built with durability in mind, the T750SE features an IP-67 rated enclosure, capable of withstanding harsh conditions, water ingress, and temperature extremes ranging from –40°C to +65°C, ensuring reliable connectivity in challenging outdoor setups.

Product Key Features

  • Dual-band Wi-Fi 6 (802.11ax) with 4×4:4 spatial streams per band
  • Integrated 120° sector antenna; external antenna support available
  • Multi-gigabit connectivity: 2.5GbE, 1GbE, SFP fiber, GPS support, PoE in/out
  • Onboard BLE, Zigbee radios with pluggable IoT module support
  • Supports up to 1,024 concurrent clients with MU-MIMO, OFDMA, and BeamFlex+
  • Integrated OTDR for built-in fiber diagnostics
  • Ruggedized IP-67 outdoor design with –40°C to +65°C operating range

Reliability & Performance :

The T750SE is engineered for ultra-reliable outdoor operation with IP-67 rating and wide operating temperature support. Its BeamFlex+ adaptive antenna technology offers over 4,000 possible antenna patterns, intelligently optimizing coverage in congested environments. MU-MIMO and OFDMA maximize efficiency while a built-in OTDR provides real-time visibility into fiber line health, reducing troubleshooting costs. Combined with robust management options, it ensures a performance-driven, enterprise-ready wireless solution.

Key Features :

  • Dual-band Wi-Fi 6 (4×4:4 streams per band)
  • Throughput: 2.4Gbps (5GHz) + 1.148Gbps (2.4GHz), aggregate ~3.548Gbps
  • Integrated 120° sector antenna with optional external antenna capability
  • Multi-gigabit backhaul (2.5GbE, 1GbE, SFP fiber, GPS, PoE in/out)
  • Onboard BLE and Zigbee radios with IoT expandability
  • MU-MIMO, OFDMA, and BeamFlex+ antenna technology
  • Supports up to 1,024 concurrent users
  • Integrated OTDR fiber diagnostic tool
  • Rugged IP-67 design for outdoor environments (–40°C to +65°C)
  • Centralized or cloud-based management support

Technical Specifications :

SpecificationDetails
Model Number 9U1-T750-US51 (T750SE)
Product Type Outdoor Wi-Fi 6 (802.11ax) Access Point with Sector Antenna
Bands Dual-band: 2.4 GHz & 5 GHz
Spatial Streams 4×4:4 both 2.4GHz and 5GHz
Max PHY Rate 2.4 Gbps (5GHz); 1.148 Gbps (2.4GHz)
Aggregate Throughput ~3.548 Gbps
Antenna 120° integrated sector antenna; optional external
Ports / Connectivity 1× 2.5GbE, 1×1GbE, 1×SFP fiber, GPS, PoE in/out
Client Capacity Up to 1,024 users
IoT Radios BLE, Zigbee, pluggable IoT modules
Fiber Diagnostics Integrated OTDR for real-time fiber monitoring
Environmental Rating IP-67, –40°C to +65°C operation
Management Options Cloud-managed, physical/virtual controller, or standalone Unleashed
