HPE Proliant P16006-001 MicroServer Gen10+ E-2224 Quad-Core 16GB

New

HPE Proliant P16006-001 MicroServer Gen10+ E-2224 Quad-Core...

×




  • New

Detailed Specifications

HPE P16006-001

ProLiant MicroServer Gen10 Plus – P16006‑001 (Intel Xeon E‑2224, 16 GB DDR4)

The HPE ProLiant MicroServer Gen10 Plus, model P16006‑001, is an ultra-compact tower server—powered by the Xeon E‑2224 CPU and 16 GB ECC RAM—designed for small businesses and remote sites needing reliable, affordable  on-prem compute. With four drive bays, four NICs, and robust security features, it punches above its size class.

Features

Packaged in a micro-form factor (11.6 × 24.5 × 24.5 cm), it features a Xeon E‑2224 (4‑core, 3.4 GHz, Turbo up to ~4.6 GHz) with ECC memory support on two DIMM slots (up to 32 GB) Storage includes four LFF SATA bays (non-hot-plug) and an embedded S100i RAID controller, plus an internal M.2 slot via PCIe for caching or boot devices .

Advanced Options

Networking is well provisioned with a quad-port Intel i350-AM4 GbE controller, ideal for VLANs or virtualization workloads . For management, the server supports iLO 5 with Silicon Root of Trust—but requires the optional iLO Kit for full remote-control functionality.

Product Key Features

    •  Intel Xeon E‑2224 (4-core, 3.4 GHz, 8 MB L3 cache, 71 W) — ideal for small business

    •  16 GB DDR4 ECC RAM (1×16 GB UDIMM; upgradable to 32 GB)

    • Four 3.5″ non-hot-plug SATA bays + internal M.2 slot; Smart Array S100i RAID

    •  Ultra-compact tower: only 4.6″ tall; can sit flat or stand

    •  Quad-port Gigabit Ethernet (Intel i350-AM4)

    •  iLO 5 Silicon Root of Trust (iLO Kit required); TPM support

Reliability & Performance

Designed for secure, unmanaged environments, the server boasts robust firmware integrity via iLO 5 and ECC memory. Despite its compact size, it offers full tower flexibility with PCIe 3.0 x16 expansion for NICs or RAID cards. The external 180 W power adapter keeps noise and heat low, and the height-adjustable chassis supports both vertical and horizontal placement

Key Features :

    • Intel Xeon E‑2224 CPU (4 cores, 8 MB cache)

    • 16 GB DDR4 ECC (1×16 GB, expandable to 32 GB)

    • Four 3.5″ SATA drive bays + internal M.2 slot (S100i RAID)

    • Quad-port Gigabit Ethernet (Intel i350-AM4)

    • PCIe 3.0 x16 low-profile slot

    • Compact 4.6″ tall tower—floor or rack-ready

    • iLO 5 with silicon-based security (Kit required)

SpecificationDetails
Model Number P16006‑001
Chassis Ultra-micro tower, 4.6″ (11.7 cm) height; horizontal/vertical placement supported
Processor Intel Xeon E‑2224, 4 cores @ 3.4 GHz (Turbo ~4.6 GHz), 8 MB L3, 71 W TDP
Memory 16 GB DDR4 ECC UDIMM (1 slot used) / 2 slots total; expandable to 32 GB @2666 MT/s
Drive Bays 4× 3.5″ SATA (non-hot-plug); internal M.2 slot for cache/boot
RAID Controller Embedded HPE Smart Array S100i (RAID 0/1/5/10)
Expansion Slot 1× PCIe 3.0 x16 (low-profile)
Networking Quad 1 GbE ports (Intel i350-AM4)
Power Supply 180 W external adapter
Management iLO 5 support (Kit P13788‑B21 recommended); TPM optional
Security Features Silicon Root of Trust, ECC memory support
Dimensions (WxDxH) 9.65″ × 9.65″ × 4.6″ (24.5×24.5×11.7 cm)
Weight ~9.3 lb (4.23 kg)
