HPE Aruba JL725A Ethernet Switch 24 Port View larger
Previous Next

HPE Aruba JL725A Ethernet Switch 24 Port

New

In Stock

HPE Aruba JL725A 24-Port Ethernet Switch Reliable High-Performance Network...

×




$1,290.00

  • New

Detailed Specifications

HPE JL725A

Aruba JL725A CX 6200F 24G PoE+ Switch – 24×1G RJ‑45 PoE+ & 4×1/10G SFP+

The HPE Aruba JL725A CX 6200F is a stackable, PoE-powered access switch ideal for enterprise edge, SMB, and campus environments. It combines 24 high-power PoE+ ports with robust SFP+ uplinks and ArubaOS‑CX intelligence to deliver simple deployment, cloud-managed operations, and rich analytics.

Features

Built on the Aruba Gen7 ASIC, the JL725A provides wire-speed L2/L3 switching, advanced features like OSPF routing, VSF stacking, and seamless integration with Aruba Central and CX Mobile apps.

Advanced Options

The PoE+ capability (370 W budget) supports devices such as APs, IP cameras, and phones. For uplinks, the 4 SFP+ ports accommodate 1 GbE or 10 GbE transceivers or DACs for flexible network expansion.

Product Key Features

  •  24×1 GbE PoE+ RJ‑45 ports, each delivering up to 30 W (Class 4 PoE)

  •  4×1/10 GbE SFP+ uplink ports for high-speed aggregation

  •  Powered by ArubaOS‑CX with Network Analytics Engine (NAE), REST API, and Aruba Central integration

  •  VSF stacking – up to 8 switches can operate as a single virtual chassis

  •  128 Gbps non-blocking switching capacity, ~95.2 Mpps forwarding

  •  Enterprise features: ACLs, QoS, VLANs, static/routed VLANs, OSPF, multicast

Reliability & Performance

With 128 Gbps switching capacity and up to 95.2 Mpps, the JL725A handles heavy edge loads reliably . Fixed internal PSU and fan ensure operational simplicity. For redundancy and greater power needs, Aruba's 6300-series offers modular PSUs.

Key Features ;

    • 24×1 GbE PoE+ ports, 370 W total budget

    • 4×1/10 GbE SFP+ uplinks

    • ArubaOS‑CX with NAE, REST API, Aruba Central

    • VSF stacking (up to 8 units)

    • L2/L3 support: VLAN, ACLs, QoS, static IP, OSPF, multicast

    • 128 Gbps switching capacity, ~95 Mpps forwarding

    • Fixed PSU, fixed fans, 1U rack-mount chassis

SpecificationDetails
Model Number JL725A
Product Type CX 6200F Stackable PoE+ Access Switch
Port Types 24 × 10/100/1000 RJ‑45 PoE+; 4 × 1/10 GbE SFP+ uplinks
PoE Standard IEEE 802.3af/at Class 4 (up to 30 W per port)
PoE Budget 370 W total
Uplink Flexibility Supports 1 GbE or 10 GbE with SFP+/DAC
Switching Capacity 128 Gbps non-blocking
Forwarding Rate Up to 95.2 Mpps
CPU / Memory ARM Cortex‑A72 @1.8GHz, 8 GB DDR4, 16 GB eMMC
Packet Buffer 8 MB
Stacking VSF – up to 8 members
Management Interfaces CLI, Web GUI, REST API, Aruba Central, CX Mobile, SNMP
Routing/Features VLAN, ACLs, OSPF, static routing, multicast, QoS
Dimensions (H×W×D) 1.73″ × 17.4″ × 12.9″ (4.39 × 44.2 × 32.7 cm)
Weight ~4.9 kg (10.8 lb)
Power Input Internal fixed 500 W AC PSU
Power Consumption (Idle) ~65 W typical (without PoE)
Operating Temp 0–45 °C (32–113 °F) up to 5,000 ft
Airflow Front-to-back
