| Ethernet LAN features |
|---|
| Ethernet WAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| DSL features |
|---|
| DSL WAN |
Yes |
| Mobile network |
|---|
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| 3G |
No |
| 4G |
No |
| Network |
|---|
| Wake-on-LAN ready |
Yes |
| Guest access |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| VPN support |
PPTP, OpenVPNTM, L2TP IPSec |
| Port forwarding |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n |
| Protocols |
|---|
| DMZ support |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| Supported network protocols |
IPv4, IPv6, FTP, FTP SSL / TLS, SFTP |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Management features |
|---|
| Universal Plug and Play (UPnP) |
Yes |
| WPS push button |
Yes |
| Web-based management |
Yes |
| Wake-on-LAN ready |
Yes |
| Reset button |
Yes |
| Security |
|---|
| VPN support |
PPTP, OpenVPNTM, L2TP IPSec |
| Security algorithms |
WEP, WPA, WPA2, WPS |
| MAC address filtering |
Yes |
| Guest access |
Yes |
| Firewall security |
IPv4, IPv6 |
| Firewall |
Yes |
| DoS attack prevention |
Yes |
| DMZ support |
Yes |
| Filtering |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| Performance |
|---|
| Processor frequency |
1700 MHz |
| Processor cores |
2 |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Compatible memory cards |
SD, SDHC, SDXC |
| Built-in processor |
Yes |
| Memory card slot(s) |
Yes |
| Certificates |
|---|
| Certification |
RoHS, CE, FCC, NCC, RCM |
| Digital Living Network Alliance (DLNA) certified |
Yes |
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| DSL WAN |
Yes |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| Wireless LAN features |
|---|
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) |
1733 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (first band) |
800 Mbit/s |
| WLAN data transfer rate (second band) |
1733 Mbit/s |
| Ports & interfaces |
|---|
| USB port |
Yes |
| USB 2.0 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
5 |
| DC-in jack |
Yes |
| Compatible memory cards |
SD, SDHC, SDXC |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Memory card slot(s) |
Yes |
| Design |
|---|
| Product type |
Tabletop router |
| On/off switch |
Yes |
| Product colour |
Black |
| Software |
|---|
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Mac compatibility |
Yes |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Antenna |
|---|
| Antenna design |
External |
| Antennas quantity |
4 |
| Antenna gain level (max) |
4.5 dBi |
| Features |
|---|
| Processor frequency |
1700 MHz |
| Processor cores |
2 |
| Certification |
RoHS, CE, FCC, NCC, RCM |
| Built-in processor |
Yes |
| Harmonized System (HS) code |
85176990 |
| Power |
|---|
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
5 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Operating altitude |
0 - 196850.4" (0 - 5000 m) |
| System requirements |
|---|
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Mac compatibility |
Yes |
| Weight & dimensions |
|---|
| Width |
11" (280 mm) |
| Weight |
24.7 oz (700 g) |
| Height |
3.03" (77 mm) |
| Depth |
6.65" (169 mm) |
| Packaging data |
|---|
| Quick start guide |
Yes |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
