Detailed Specifications
Ruckus 901-R730-US00 - Indoor Wi-Fi 6 Access Point with Multi-Gigabit Backhaul
Overview :
The Ruckus 901-R730-US00 is an enterprise-grade indoor wireless access point (AP) built for ultra-high density environments such as stadiums, auditoriums and large public venues where thousands of users connect simultaneously. It delivers dual-band Wi-Fi 6 (802.11ax) with 12 spatial streams (8×8:8 in 5GHz and 4×4:4 in 2.4GHz) to manage heavy client loads and high bandwidth demands. The device integrates a multi-gigabit Ethernet backhaul interface including a 5 Gbps port and a 1 Gbps port, enabling high throughput beyond conventional gigabit uplinks. Advanced RF features such as BeamFlex+ adaptive antennas and OFDMA/MU-MIMO enable better coverage and performance in dense deployments. The unit supports PoE (802.3at/af) or 48V DC power input, and is manageable via Ruckus appliance, virtual or cloud-based controllers.
Key Features :
12 spatial streams (8×8:8 + 4×4:4) for 802.11ax capacity
Multi-gigabit backhaul: 5 GbE + 1 GbE ports
BeamFlex+ adaptive antennas for optimized coverage
Supports up to 1,024 clients per AP in dense scenarios
PoE/48V DC dual-mode power input flexibility
Specifications
| Specification | Detail |
|---|
| Brand | Ruckus |
| Part Number | 901-R730-US00 |
| Product Type | Indoor Wi-Fi 6 (802.11ax) Access Point |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax |
| Spatial Streams | 8×8:8 @ 5GHz, 4×4:4 @ 2.4GHz |
| Maximum PHY Rate | Up to 4.8 Gbps @ 5GHz + 1.148 Gbps @ 2.4GHz |
| Ethernet Ports | 1× 5 GbE (RJ-45) + 1× 1 GbE (RJ-45) |
| Antenna Gain (max) | Up to 2 dBi |
| Power Input | 802.3at PoE or 48 V DC |
| Mounting | Ceiling or wall mount bracket included |
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Dimensions (H×W×D) | 2.36 in × 9.83 in × 8.74 in |
| Weight | 3.37 lbs |
| SmartMesh Support | Yes |
| Security | WPA3, WIPS/WIDS, Dynamic PSK |
