Sophos AP6 420 AP420U00ZZPCNP Wireless Access Point

Detailed Specifications

Sophos

AP6 420 AP420U00ZZPCNP Wireless Access Point

The Sophos AP6 420 AP420U00ZZPCNP is a high-performance WiFi 6 Access Point engineered for small to medium enterprises and high-density environments. Delivering fast, reliable wireless connectivity, it supports the latest 802.11ax standard, ensuring higher throughput, lower latency, and improved device capacity. Ideal for applications such as video conferencing, cloud services, VoIP, and large file transfers, it enables smooth and uninterrupted performance even with multiple connected devices.

Features

Dual-band operation, combined with advanced OFDMA and MU-MIMO technologies, efficiently manages network traffic, minimizing congestion and maximizing network efficiency. Designed for seamless integration with SophosCentral and Sophos XG management platforms, the AP6 420 simplifies deployment, monitoring, and firmware updates. Its flexible mounting options—wall, ceilin table—along with Power over Ethernet (PoE) support, provide versatile installation while maintaining enterprise-grade security and robust wireless performance across office environments.

Advanced Options

The AP6 420 delivers reliable, high-speed wireless connectivity through WiFi 6 technology, supporting dual-band operation for optimized coverage and performance. The 2×2 MIMO configuration on both 2.4 GHz and 5 GHz bands provides fast and stable connections for multiple clients simultaneously. OFDMA and MU-MIMO enable efficient multi-device communication, reducing latency and network congestion in dense environments.

Product Key Features

  • WiFi 6 (802.11ax) dual-band access point for small to medium enterprises

  • OFDMA and MU-MIMO for efficient multi-device connectivity

  • Seamless integration with Sophos Central and XG Firewall management

  • Flexible PoE installation with wall, ceiling, or table mounting

  • Enterprise-grade security, firmware updates, and seamless roaming


Reliability & Performance

The Sophos AP6 420 AP420U00ZZPCNP provides consistent, high-speed wireless connectivity for enterprise environments. Dual-band WiFi 6 operation ensures low-latency, high-throughput connections for multiple devices simultaneously, while OFDMA and MU-MIMO technologies optimize bandwidth allocation in high-density environments. Mesh capabilities allow seamless roaming between APs without interruptions, and PoE support simplifies deployment while reducing cabling complexity. Integration with Sophos Central or XG Firewall enables centralized monitoring, configuration, and automatic firmware updates, ensuring security and reliability.

Key Features (Bullet List)

  • WiFi 6 (802.11ax) dual-band access point

  • OFDMA and MU-MIMO for multi-device efficiency

  • Integration with Sophos Central and XG Firewall management

  • PoE support with wall, ceiling, or table mounting

  • Enterprise-grade security, firmware updates, and seamless roaming

Specifications :

SpecificationDetails
Model Number AP420U00ZZPCNP
Type WiFi 6 Access Point (802.11ax)
WiFi Standard WiFi 6 (802.11ax)
Bands Dual-band (2.4 GHz + 5 GHz)
Speed Up to 1.8 Gbps combined
MIMO Configuration 2×2 on both 2.4 GHz and 5 GHz
OFDMA / MU-MIMO Yes
Ports 1 × 1GbE PoE port, 1 × RJ45 management port
Mounting Options Ceiling, wall, or table
Security WPA3, WPA2, Enterprise-class security
Management Sophos Central, Sophos XG Firewall
Dimensions 7.5 × 7.5 × 1.9 in (190 × 190 × 48 mm)
Weight 1.65 lb (0.75 kg)
Power PoE 802.3at compliant
Operating Temp 0 °C – 40 °C
