Mikrotik CCR2004-16G-2S+PC

Cloud Core Router - Passive Cooled Ethernet Router with 16x Gigabit Ports & 2x 10G SFP+

The MikroTik CCR2004-16G-2S+PC Cloud Core Router is a high-efficiency, passively cooled routing solution tailored for ISPs, enterprise networks, and cloud providers. It features 16 Gigabit Ethernet ports, 2x 10G SFP+ uplinks, and a quad-core 64-bit ARM CPU, delivering powerful performance in a silent, rackmountable package.

Features

The "PC" in the CCR2004-16G-2S+PCmodel stands for Passive Cooling, offering a completely silent operation without compromising on performance. This makes it perfect for environments where noise is a concern, such as offices, studios, or shared network spaces.

Advanced Options

Powered by a quad-core ARMv8 Cortex-A57 CPU running at 1.7 GHz, and paired with 4 GB DDR4 RAM, this router easily handles dynamic routing protocols, firewall rules, VPN tunnels, and other advanced networking functions. With RouterOS Level 6 pre-installed, it supports BGP, OSPF, MPLS, VLANs, and traffic shaping×all within a single appliance.

Product Key Features

• • 64-bit ARM Cortex-A57 quad-core CPU for fast and efficient routing

  • Includes 16x Gigabit Ethernet ports and 2x 10G SFP+ cages for fiber uplinks

  • Runs RouterOS Level 6 with advanced Layer 3 features and full software suite

  • Completely silent, fanless design for office or rack use

  • Dual redundant power inputs for continuous uptime

  • Ideal for enterprise cores, data centers, or service provider edge routing

Reliability & Performance

Designed for silent operation and long-term uptime, the router features passive cooling (no moving parts), along with dual redundant power inputs for hardware resilience. It is ideal for enterprise-grade routing at the edge or aggregation layer. The SFP+ cages support 10G fiber uplinks, while the 16 Gigabit Ethernet ports offer ample copper connectivity for internal LANs or downstream devices.

Key Features :

• • Quad-core 64-bit ARM Cortex-A57 @ 1.7 GHz

  • 16x Gigabit Ethernet ports

  • 2x SFP+ 10G fiber uplinks

  • 4 GB DDR4 RAM

  • 128 MB NAND storage

  • RouterOS Level 6 license included

  • Passive cooling - completely silent

  • 1U rackmount form factor

  • Dual redundant power inputs

  • Advanced Layer 3 routing protocols and firewall support

Specification	Details
Model Number	CCR2004-16G-2S+PC
Product Type	Cloud Core Ethernet Router
CPU	4-core ARM Cortex-A57 @ 1.7 GHz
RAM	4 GB DDR4
Storage	128 MB NAND
Operating System	RouterOS Level 6
Ethernet Ports	16 × 10/100/1000 Mbps RJ45
SFP+ Ports	2 × 10G SFP+
Max Throughput	~3-5 Gbps (real-world)
Cooling	Passive (silent, fanless)
Power Supply	Dual DC inputs (redundant power supported)
Form Factor	1U rackmount
Dimensions	17.4" x 5.7" x 1.7" (443 x 145 x 44 mm)
Weight	~5.3 lbs (2.4 kg)
Operating Temperature	32°F to 122°F (0°C to 50°C)
