Detailed Specifications

Addon

WS‑G5486‑AO Compatible with Cisco WS‑G5486, 1000Base‑LX GBIC Transceiver, Single‑Mode Fiber 10 km, SC Connector

The Addon WS‑G5486‑AO is a fully compatible replacement for the Cisco WS‑G5486 GBIC Transceiver, engineered to deliver Gigabit Ethernet over long-haul single-mode optical links. Supporting 1000Base‑LX transmission over SMF with a maximum reach of up to 10 km via duplex SC connectors, it uses a 1310 nm wavelength laser for stable, low-error signal delivery. This plug-and-play module is factory-programmed, uniquely serialized, and tested for compatibility with Cisco and MSA-compliant ports, ensuring flawless integration into enterprise network installations and fiber backbone infrastructures.

Features

Designed to meet or exceed Cisco OEM specifications, the WS‑G5486‑AO adheres to SFF‑8053 (mini‑GBIC) MSA standards and offers hot-swappable convenience for field maintenance or network upgrades. Its rugged metal housing provides EMI shielding and thermal stability in high-density switch chassis. Each module undergoes factory-level serialization and traffic testing to ensure immediate port recognition and consistent link behavior

Advanced Options

 With support for both 1000Base‑LX and LH standards over 9/125 µm SMF, the Transceiver is ideal for inter-building connections, campus backbone links, and enterprise WAN backhaul deployments. It is TAA compliant and RoHS certified, making it suitable for public sector and regulated procurement.

Product Key Features

  • 1000Base‑LX/LH Gigabit Ethernet over single-mode fiber

  • Supports link distances up to 10 km (9/125 µm SMF) at 1310 nm

  • Duplex SC connector interface for secure fiber coupling

  • Fully Cisco WS‑G5486 compatible, factory-programmed and serialized

  • Hot-pluggable GBIC (mini‑GBIC) module form factor; EMI-shielded metal housing

  • Compliant with MSA standards, RoHS, and TAA regulations

  • Backed by lifetime limited warranty

Reliability & Performance

Built for high-reliability environments, the Addon WS‑G5486‑AO delivers consistent Gigabit performance with power-consumption around 250 mA @ 3.3 V (~0.8 W). Its optimized optics offer transmitter output between –9 to –3 dBm and receiver sensitivity to –20 dBm, ensuring proper link margins at distances up to 10 km. Each unit passes optical and electrical testing for low bit error rates, and its hot-swappable, metal-encased design enhances both durability and EMI protection. Operating safely between 0 °C to 70 °C (storage –40 °C to 85 °C), this GBIC ensures dependable operation in data centers, cross-site fiber installations, and enterprise backbone networks.

Key Features (Bullet List)

  • 1000Base‑LX/LH over 10 km single-mode fiber

  • SC duplex connector interface

  • Cisco WS‑G5486-compatible with OEM-level serialization

  • Hot-swappable mini‑GBIC form factor

  • 1310 nm wavelength, metal housing with EMI protection

  • RoHS- and TAA-compliant; lifetime limited warranty

Specifications :

SpecificationDetails
Model Number WS‑G5486‑AO
Product Type GBIC Transceiver Module (mini‑GBIC / SFP)
Data Rate 1 Gbps (1000Base‑LX/LH)
Fiber Type & Core Single-mode Fiber (SMF, 9/125 µm)
Transmission Wavelength 1310 nm
Maximum Distance Up to 10 km
Connector Type Duplex SC
Form Factor GBIC (SFF‑8053 compliant, hot-pluggable)
Transmit Power ‑9 to ‑3 dBm
Receiver Sensitivity ≤ ‑20 dBm
Power Supply 3.3 V ±5%
Power Consumption ~250 mA (~0.8 W)
Operating Temperature 0 °C to 70 °C
Storage Temperature –40 °C to 85 °C
Compliance MSA, RoHS, TAA
Warranty Limited Lifetime Warranty
