Addon Aa1419039-e5-ao 1000base-xd Cwdm Smf Sfp Nortel 1590nm 70km View larger

Addon Aa1419039-e5-ao 1000base-xd Cwdm Smf Sfp Nortel 1590nm 70km

New

AddOn 1000BASE-XD CWDM SFP, 70KM SMF for Nortel
×




  • New

Detailed Specifications

AddOn AA1419039-E5-AO

1000BASE-XD CWDM SMF SFP Transceiver Nortel 1590nm 70km

The AddOn AA1419039-E5-AO is a reliable 1000BASE-XD CWDM SFP transceiver purpose-built for Nortel and compatible systems. Operating on the 1590nm wavelength, it supports Gigabit Ethernet transmission over single‑mode fiber (SMF) at distances of up to 70 kilometers, making it suitable for long‑haul metro, enterprise and service provider networks.

As a premium AddOn solution, this transceiver ensures OEM‑level compatibility and cost-effective performance. It delivers consistent reliability for mission‑critical applications where extended reach and stable data transmission are required.

Features :

This optical module is hot‑pluggable and built on the 1000BASE‑XD CWDM standard. It features LC duplex interfaces, Digital Diagnostics Monitoring (DDM), and offers reduced power consumption while operating efficiently on CWDM wavelengths to maximize fiber utilization across diversified networks.

Advanced Options :

With CWDM optics, the AA1419039-E5-AO allows operators to leverage multiple wavelength channels on a single fiber strand, drastically improving network scalability. Its 1590nm optical channel and 70km range make it the perfect choice for metro Ethernet, data centers, and cross-campus backbone connections.

Product Key Features

  • 1000BASE‑XD CWDM compliant SFP module
  • Designed for Nortel and OEM compatible systems
  • 1590nm CWDM wavelength operation
  • Reach up to 70km over SMF
  • LC duplex connector
  • Supports Digital Diagnostics Monitoring (DDM)
  • Hot‑pluggable design for easy deployment
  • Backed by AddOn quality and warranty

Reliability & Performance :

The AddOn AA1419039-E5-AO is engineered for maximum stability and uptime over extended distances. With low signal loss, enhanced monitoring features, and CWDM channel allocation, it guarantees dependable 1.25Gbps data rates under demanding conditions, making it an excellent investment for long‑distance enterprise or carrier networks.

Key Features :

  • 1.25Gbps Gigabit Ethernet transmission
  • 1000BASE‑XD CWDM single‑mode support
  • Operates at 1590nm CWDM channel
  • Maximum range up to 70km
  • Hot‑pluggable SFP form factor
  • Supports LC duplex connectors
  • Compatible with Nortel and OEM equipment
  • Supported by AddOn warranty

Specifications :

SpecificationDetails
Part Number AA1419039-E5-AO
Brand AddOn
Product Type 1000BASE‑XD CWDM SMF SFP Transceiver
Form Factor SFP (Small Form‑factor Pluggable)
Data Rate 1.25 Gbps
Standard 1000BASE‑XD CWDM
Wavelength 1590nm
Connector LC Duplex
Fiber Type Single‑Mode Fiber (SMF)
Maximum Distance 70 km
Compatibility Nortel and OEM compatible switches
Hot‑pluggable Yes
Features Digital Diagnostics Monitoring (DDM)
Power Consumption Low
Operating Temperature 0°C to 70°C
Storage Temperature -40°C to 85°C
Compliance RoHS, IEEE 802.3z
Housing Durable metallic casing
Warranty Backed by AddOn Warranty
Application Enterprise, Data Centers, Carrier Networks
Color Standard metallic finish
