ENET J9150D-LRM-ENC HP Aruba Compatible 10Gbase-LRM SFP+ 1310nm 220m MMF Duplex LC Transceiver

ENET J9150D-LRM-ENC

HPAruba Compatible 10Gbase-LRM SFP+ 1310nm 220m MMF Duplex LCTransceiver

A reliable 10G SFP+transceiver for short-distance fiber optic links.

Overview :

The ENET J9150D-LRM-ENC is a compatible 10GBASE-LRM SFP+transceiver designed for HPArubanetworking equipment. It supports short-reach 10 Gigabit Ethernet connections over multimode fiber, with a maximum distance of 220 meters, making it ideal for enterprise data centers, wiring closets, and campus backbone links requiring efficient high-speed fiber connectivity.

Features :

This transceiver module transmits at 1310 nm wavelength and interfaces via duplex LC connectors, supporting multimode fiber infrastructure. It is designed to meet the Multi-Source Agreement (MSA) standards ensuring interoperability across HPAruba devices and other compliant equipment. The 220m reach suits short-distance fiber links within buildings or between nearby buildings, supporting high-bandwidth applications reliably. The device offers Digital Optical Monitoring (DOM) allowing network administrators to track real-time operating parameters such as temperature, voltage, and optical output power. Additionally, its hot-pluggable form factor facilitates efficient network maintenance and upgrades without causing downtime.

Product Key Features

• Supports 10 Gigabit Ethernet data rate.
• Operates at 1310 nm wavelength for multimode fiber (MMF).
• Transmission distance up to 220 meters.
• Duplex LC connector for fiber optic networks.

---

Reliability & Performance :

Constructed with a robust metal casing, the J9150D-LRM-ENC delivers stable and reliable performance in enterprise networking environments. It consumes low power and is tested for compatibility with HPArubaswitches, ensuring plug-and-play functionality. The built-in monitoring features and durable design support network stability and proactive maintenance.

Key Features :

• 10GBASE-LRM SFP+transceiver for multimode fiber.
• 1310 nm wavelength, 220-meter maximum distance.
• Duplex LC connector interface.
• HPAruba compatible and MSA compliant.
• Hot-swappable with Digital Optical Monitoring (DOM).
• Low power consumption.

Specifications :

Specification	Description
Model Number	J9150D-LRM-ENC
Product Type	10GBASE-LRM SFP+Transceiver
Data Rate	10 Gbps
Fiber Type	Multimode fiber (MMF)
Connector Type	Duplex LC
Wavelength	1310 nm
Transmission Distance	Up to 220 meters
Power Consumption	< 1 W
Hot-pluggable	Yes
Digital Diagnostics	Supported (DOM)
Compatibility	HPAruba compatible
MSA Compliance	Yes
