ENET J9151E-BX80U-ENC HP Aruba Compatible 10Gbase-ZR Bidi SFP+ 1490nm 1550nm 80km SMF Simplex LC Transceiver

ENET J9151E-BX80U-ENC

HPAruba Compatible 10Gbase-ZR BidiSFP+ 1490nm 1550nm 80km SMF Simplex LCTransceiver

A bidirectional SFP+transceiver for long-distance 10G connections.

Overview :

The ENET J9151E-BX80U-ENC is a high-performance 10Gbase-ZR bidirectionalSFP+transceiver designed for compatibility with HPArubanetworking equipment. It supports long-distance 10G connectivity over single-mode fiber up to 80 kilometers using dual wavelengths (1490 nm and 1550 nm) to enable cost-effective fiber infrastructure usage via a duplex-like link on a single fiber strand.

Features :

This bidirectional (BiDi) SFP+transceiver utilizes a single fiber strand for both transmit and receive signals via different wavelengths, reducing fiber cable requirements. The simplex LC connector type facilitates easy installation into fiber systems needing space and cable management optimization without compromising performance. Designed specifically for HPAruba devices, the J9151E-BX80U-ENC module meets Multi-Source Agreement (MSA) standards, ensuring broad interoperability across various compatible switches and routers. It provides reliable and low-latency 10 Gbps Ethernet communication for critical applications such as data center interconnects and metro network links. Its extended 80 km reach ensures flexible deployment in enterprise WAN environments and campus backbones without the need for repeaters or signal boosters, supporting efficient network design over long distances.

Product Key Features

• 10 Gigabit Ethernet 10Gbase-ZR standard.
• Bidirectional SFP+ with 1490 nm and 1550 nm wavelengths.
• Supports up to 80 km over single-mode fiber (SMF).
• Simplex LC connector for fiber efficiency.

---

Reliability & Performance :

The transceiver's robust design includes a sturdy metal housing that withstands environmental pressures common in enterprise deployments. It supports Digital Optical Monitoring (DOM) to allow continuous monitoring of real-time parameters such as temperature, voltage, and optical power for proactive maintenance. Hot-swappable design promotes seamless integration or replacement without downtime.

Key Features :

• 10Gbase-ZR 10 Gbps transceiver with BiDi technology.
• Dual wavelengths at 1490 nm (Tx) and 1550 nm (Rx).
• 80 km maximum transmission over single-mode fiber.
• Simplex LC connector for single fiber utilization.
• HPAruba compatible and MSA compliant.
• Hot-pluggable with digital diagnostics monitoring.

Specifications :

Specification	Description
Model Number	J9151E-BX80U-ENC
Product Type	10Gbase-ZR BiDiSFP+Transceiver
Data Rate	10 Gbps
Fiber Type	Single-mode fiber (SMF)
Connector Type	Simplex LC
Wavelength	Tx: 1490 nm / Rx: 1550 nm
Transmission Distance	Up to 80 km
Power Consumption	< 1.5 Watts
Hot-pluggable	Yes
Digital Diagnostics	Supported (DOM)
Compatibility	HPAruba compatible
MSA Compliance	Yes
