MikroTik CRS310-1G-5S-4S+OUT

netFiber 9 – Outdoor Fiber Switch with 1x Gigabit, 5x 1G SFP & 4x 10G SFP+ Ports

The MikroTik CRS310-1G-5S-4S+OUT netFiber 9 is a compact, outdoor-ready fiber aggregation switch, designed for high-throughput distribution in fiber-based networks. Featuring 9 total SFP/SFP+ ports (5x 1G, 4x 10G) and a Gigabit Ethernet port with PoE-in, this rugged switch excels in wireless tower setups, campus links, and ISP edge locations.

Features

Built inside a tough IP66 weatherproof enclosure, the netFiber 9 is engineered for long-term performance in demanding outdoor environments. It uses a dual-core 800 MHz ARM CPU and 256 MB RAM, delivering fast switching with advanced Layer 3 control through RouterOS, or simplified config via SwOS.

Advanced Options

Ideal for fiber-rich outdoor topologies, the switch handles up to 72 Gbps switching capacity, making it a go-to solution for connecting sector antennas, backbone uplinks, or remote PoPs. Its passively cooled design and sealed housing ensure silent, low-maintenance operation, even in extreme weather.

Product Key Features

    • Outdoor-rated switch with 5x 1G SFP and 4x 10G SFP+ cages for fiber-rich environments

    •  Includes 1x Gigabit Ethernet port for PoE input and management

    •  Rugged IP66 weatherproof enclosure – built for harsh outdoor deployments

    •  Dual boot system: RouterOS Level 5 and SwOS support advanced or simple management

    • Fanless passive cooling for silent and durable performance

    •  Powered via PoE-in (802.3af/at) or DC jack – flexible power options

Reliability & Performance

With no fans and an IP66-rated housing, the CRS310-1G-5S-4S+OUT is optimized for dust, rain, and wind resistance. The SFP+ cages support 10G uplinks for backhaul links, while PoE input via Gigabit Ethernet enables simple tower or rooftop deployments using a single cable. The unit is preloaded with RouterOS Level 5, supporting VLANs, ACLs, traffic shaping, and static routing.

Key Features :

    • 5x 1G SFP fiber ports

    • 4x 10G SFP+ high-speed uplinks

    • 1x Gigabit Ethernet port (PoE-in supported)

    • Dual-core ARM CPU @ 800 MHz

    • 256 MB RAM, 16 MB Flash

    • RouterOS Level 5 license & SwOS dual boot

    • IP66-rated waterproof and dustproof enclosure

    • Passive cooling – no fans

    • Powered via PoE-in (802.3af/at) or DC jack

    • Built for tower, rooftop, and outdoor aggregation

SpecificationDetails
Model Number CRS310-1G-5S-4S+OUT (netFiber 9)
Product Type Outdoor Cloud Router Switch
CPU Dual-core ARM 800 MHz
RAM 256 MB
Storage 16 MB Flash
Operating System RouterOS Level 5 / SwOS (dual boot)
Ethernet Ports 1 × Gigabit RJ45 (PoE-in)
SFP Ports 5 × 1G SFP
SFP+ Ports 4 × 10G SFP+
Switching Capacity 72 Gbps
Forwarding Rate 53.6 Mpps
Cooling Passive (fanless)
Power Input PoE-in (802.3af/at) or 12–57V DC jack
Power Consumption ~18 W max
Enclosure Rating IP66 (outdoor weatherproof)
Dimensions 11.6" × 8.7" × 2.6" (295 × 220 × 65 mm)
Weight ~2.4 lbs (1.1 kg)
Operating Temperature -40°C to +70°C (-40°F to +158°F)
