ENET J9284D-Enc HP Aruba Compatible Direct Attach Copper Cable 5m

ENET J9284D-Enc

HPAruba Compatible Direct Attach Copper Cable 5m

A cost-efficient 10G DAC cable for high-speed, short-reach connections.

Overview :

The ENET J9284D-ENC is a 5-meter passive Direct Attach Copper (DAC) Twinax cable designed for high-speed 10 Gigabit Ethernet connectivity between SFP+ ports in HPArubanetworking equipment. This cable provides a cost-efficient and low-latency solution for short-distance interconnects within data centers and telecom equipment rooms, ensuring seamless compatibility and reliable performance.

Features :

Featuring SFP+ connectors on both ends, the J9284D-ENC cable supports 10GBASE-CU Ethernet standards with a data transfer rate optimized up to 10.5 Gbps. It is designed specifically for use with HPArubaswitches, with EEPROM encoding to guarantee compatibility and plug-and-play functionality. The cable is constructed with AWG30 Twinax copper cabling, offering excellent signal integrity and durability across the full 5-meter length. It operates reliably within a standard temperature range of 0° to 70°C, making it suitable for typical network equipment room environments. The passive design significantly reduces power consumption compared to active optical modules while providing stable, low-latency connections for server-to-switch or switch-to-switch links.

Product Key Features

• 5-meter length passive Twinax DAC cable.
• SFP+ to SFP+ connectors supporting 10 Gigabit Ethernet.
• Supports data rates up to 10.5 Gbps.
• Fully compatible with HPArubaswitches and devices.

---

Reliability & Performance :

The ENET J9284D-ENC features high-quality build materials and rigorous quality testing to ensure long-lasting and stable operation in enterprise environments. It supports Digital Diagnostic Monitoring (DDM) providing real-time information on cable temperature, voltage, and signal strength to maintain network health. The hot-swappable design simplifies installation and replacement without disrupting network uptime.

Key Features :

• 5m passive SFP+ Twinax DAC cable.
• Supports 10GBASE-CU Ethernet, data rates up to 10.5 Gbps.
• SFP+ to SFP+ connectors for HPAruba compatibility.
• AWG30 copper twinax cable for signal integrity.
• Low power consumption, hot-pluggable.
• RoHS, CE compliant and MSA standard.

Specifications :

Specification	Description
Model Number	J9284D-ENC
Product Type	10G SFP+Direct Attach Copper Cable
Cable Length	5 meters
Data Rate	Up to 10.5 Gbps
Connector Type	SFP+ to SFP+
Cable Type	AWG30 Twinax Copper
Supported Standard	10GBASE-CU
Power Consumption	Approx. 0.5 W
Operating Temperature	0° to 70°C
Compliance	SFP+ MSA, RoHS, CE
Hot-pluggable	Yes
