HPE JZ332A

Aruba AP-534 US Campus Wireless Access Point - Dual-Radio Wi-Fi 6 (4×4:4 External Antennas)

The HPE Aruba AP-534 (JZ332A) is a high-performance Wi-Fi 6 access point engineered for dense campuses and enterprise environments. Featuring external antennas and comprehensive RF and security features, it delivers powerful and flexible wireless connectivity, IoT readiness, and robust uplinks×ideal for classrooms, hospital wings, and conference venues.

Features

Leveraging dual 4×4 MIMO radios, the AP-534 supports up to 2.4 Gbps on 5 GHz and 1.15 Gbps on 2.4 GHz, reaching a combined 3.55 Gbps aggregate throughput . It includes OFDMA and MU-MIMO enhancements, supporting up to 1,024 clients per radio and 37 OFDMA resource units, ensuring high efficiency in dense deployments

Advanced Options

External RP-SMA antenna support allows tailored RF coverage, suited for varied ceiling or wall environments.Built-in Bluetooth 5 and Zigbee radios enable seamless IoT integration, including asset tracking, analytics, and location services. It also hosts a USB-A port for accessory expansion.

Product Key Features

• Dual-radio Wi-Fi 6 with 4×4:4 MIMO in both 2.4 GHz and 5 GHz bands - up to 3.55 Gbps aggregate

• External RP-SMA antenna ports (4) for optimized coverage

• Aruba RF-suite: OFDMA, MU-MIMO, ClientMatch®, AirMatch®, ACC, Air Monitor

• Integrated Bluetooth 5.0 and Zigbee radios for IoT and location services

• Dual Smart Rate 5 GbE uplinks with PoE-PD, USB-A host, and micro-USB console

• Enterprise-grade security: WPA3, Enhanced Open, onboard TPM, Dynamic Segmentation

Reliability & Performance

The AP-534 offers dual 5 GbE Smart Rate uplinks with PoE-PD support, enabling link aggregation or redundant connections without external injectors . Aruba RF features×ClientMatch, AirMatch, ACC, Air Monitor×dynamically tune network performance and reduce interference for consistent connectivity Enterprise features like TPM, Dynamic Segmentation, WPA3, and Enhanced Open provide advanced security. It fits ceiling, wall, or rail mounting setups, delivering stable performance in enterprise-grade thermal and environmental conditions.

Key Features :

• • Dual-radio Wi-Fi 6 (802.11ax) with 4×4:4 MIMO

  • External RP-SMA antenna connectors (4)

  • Aggregate throughput up to 3.55 Gbps

  • Bluetooth 5 and Zigbee IoT radios

  • Two Smart Rate 5 GbE ports with PoE-PD

  • USB-A host and micro-USB console ports

  • Aruba RF intelligence suite

  • Extensive security: WPA3, Enhanced Open, TPM, Dynamic Segmentation

Specification	Details
Model Number	JZ332A (AP-534 US Campus)
Product Type	Indoor Dual-Radio Wi-Fi 6 Access Point
Wireless Standard	IEEE 802.11ax (Wi-Fi 6)
Radios	Dual 4×4 MIMO (2.4 GHz & 5 GHz)
Max Aggregate Throughput	3.55 Gbps (2.4 GHz: 1.15 Gbps; 5 GHz: 2.4 Gbps)
Antenna Ports	4× RP-SMA external
Bluetooth/Zigbee	Bluetooth 5.0, IEEE 802.15.4 (Zigbee)
Ethernet Ports	2× Smart Rate RJ-45 (1/2.5/5 GbE), PoE-PD capable
USB Port	1× USB-A (host)
Console Port	1× micro-USB
Clients Supported	Up to 1,024 per radio
OFDMA RUs	Up to 37 resource units per radio
Security	WPA3, Enhanced Open, TPM, Dynamic Segmentation
Mount Options	Ceiling, wall, rail (brackets sold separately)
Dimensions (W×D×H)	~239×239×56 mm (9.4″×9.4″×2.2″)
Weight	~1.27 kg (2.8 lb)
Power Options	PoE-PD (802.3at/af/bt), DC optional
