HPE JZ357A

Aruba AP-555 US Campus Access Point - Wi-Fi 6 Dual-Radio (8×8 + 4×4)

The HPE Aruba JZ357A AP-555 is a powerful dual-radio Wi-Fi 6 access point engineered for dense campus and enterprise environments. It combines high-capacity wireless connectivity with advanced RF intelligence and IoT integration, ensuring reliable, secure, and seamless coverage in universities, hospitals, large offices, and event venues.

Features

Aruba's 550 Series APs support up to 5.37 Gbps aggregate throughput, thanks to an 8×8 MIMO 5 GHz radio and a 4×4 MIMO 2.4 GHz radio . Technologies like OFDMA, MU-MIMO, and Target Wait Time enhance simultaneous multi-device performance. Additionally, optional tri-radio mode adds a second 5 GHz radio, perfect for ultra-high-density deployments.

Advanced Options

Built-in IoT radios (Bluetooth 5, Zigbee, NFC) enable a secure platform for location services, asset tracking, and automation Featuring dual 5 GbE Smart Rate ports (supporting 1/2.5/5 GbE), the AP offers robust uplink flexibility and PoE-PD support. Aruba's RF suite×ClientMatch®, AirMatch®, Advanced Cellular Coexistence, and Air Monitor×dynamically optimize signal allocation, client steering, and interference mitigation.

Product Key Features

• ⚡ Dual-radio Wi-Fi 6 (802.11ax) with 8×8 in 5 GHz + 4×4 in 2.4 GHz delivering up to 5.37 Gbps aggregated

• Intelligent Aruba RF: OFDMA, MU-MIMO, ClientMatch®, AirMatch®, ACC & Air Monitor

• IoT-ready with built-in Bluetooth 5, Zigbee, and NFC support

• Dual 5 GbE Smart Rate ports, PoE-PD support & optional tri-radio mode

• Enterprise-grade security: WPA3, Enhanced Open, TPM + Dynamic Segmentation

• Flexible Mounting: ceiling, wall, and rail kits available

Reliability & Performance

Enterprise security is strengthened with WPA3, Enhanced Open, onboard TPM, and Dynamic Segmentation. The AP is ceiling- and wall-mountable and holds a limited lifetime warranty.

Key Features :

• • IEEE 802.11ax dual-radio (8×8 5 GHz + 4×4 2.4 GHz), up to 5.37 Gbps aggregate

  • Aruba RF intelligence: OFDMA, MU-MIMO, ClientMatch®, AirMatch®, ACC, Air Monitor

  • Bluetooth 5, Zigbee, NFC for IoT & location services

  • Dual 5 GbE Smart Rate ports with PoE-PD, USB-A host, micro-USB console

  • WPA3, Enhanced Open, TPM, Dynamic Segmentation

  • Ceiling, wall, and rail mountable form factor

Specification	Details
Model Number	JZ357A (AP-555 US Campus AP)
Product Type	Dual-Radio Indoor Wi-Fi 6 Access Point (optional tri-radio)
Wireless Standard	IEEE 802.11ax (Wi-Fi 6)
Radios	1× 8×8 5 GHz + 1× 4×4 2.4 GHz
Max Aggregate Throughput	Up to 5.37 Gbps (dual-radio), 4.8 Gbps in dual-radio mode
IoT Radios	Bluetooth 5.0, Zigbee, NFC
Ethernet Ports	2× 5 GbE Smart Rate with PoE-PD support
USB Port	1× USB-A (host)
Console	Micro-USB for debugging
Security	WPA3, Enhanced Open, TPM, Dynamic Segmentation
Mount Options	Ceiling, wall, and rail mount capable
Dimensions (W×D×H)	~260×260×50 mm (~10.2″×10.2″×2.0″)
Weight	~1.57 kg (~3.46 lb)
