Detailed Specifications
Ubiquiti UA-G2 Dual-Band Wi-Fi 6 Access Point
Overview
The Ubiquiti UA-G2 is a dual-band outdoor Wi-Fi 6 access point designed for enterprise and campus wireless networks requiring robust coverage and high client density support. It uses 802.11ax technology with MU-MIMO and OFDMA to deliver combined throughput across 2.4 GHz and 5 GHz bands and includes dual Gigabit Ethernet ports with PoE power. The weather-resistant enclosure fits wall, pole, or ceiling deployments in exposed environments. It integrates into the UniFi Network platform for centralized provisioning, monitoring, and guest access control.
Key Features
• Dual-band 802.11ax Wi-Fi 6 support
• MU-MIMO and OFDMA technologies
• Dual Gigabit Ethernet PoE ports
• IP55 weather-resistant housing
Technical Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number | UA-G2 |
| Product Type | Outdoor Wi-Fi 6 Access Point |
| Wireless Standard | IEEE 802.11a/b/g/n/ac/ax |
| Frequency Bands | 2.4 GHz & 5 GHz |
| Maximum Throughput | ~3000 Mb/s aggregate |
| MIMO | 2×2 MU-MIMO |
| Ethernet Ports | (2) RJ45 10/100/1000 with PoE |
| Power Method | PoE (802.3af/at) |
| Power Consumption | ~12 W |
| Antenna | Internal omnidirectional |
| Weather Rating | IP55 outdoor |
| Mounting | Wall/pole/ceiling hardware supported |
| Operating Temp | −20 °C to 60 °C |
| Dimensions | 235 × 180 × 50 mm |
| Weight | ~750 g |
