Detailed Specifications
RUCKUS 901-T310-US51 – Outdoor Access Point / 120° Sector Coverage
Overview :
The RUCKUS 901-T310-US51 is an outdoor wireless access point designed for medium-to-high density outdoor venues such as plazas, campuses and smart city deployments. It supports dual-band concurrent operation on 2.4 GHz and 5 GHz with a 2×2:2 MU-MIMO radio configuration, delivering a combined PHY rate of up to 300 Mb/s on 2.4 GHz and 867 Mb/s on 5 GHz. It includes a built-in 120° horizontal × 30° vertical directional (sector) antenna, enables flexible power options (PoE input or 12 V DC terminal block) and features an IP-67 rated enclosure for rugged outdoor operation from -40 °C to +65 °C. The unit offers an RJ-45 1 GbE interface and USB 2.0 port for future expansion and IoT integration. It fits in outdoor edge, campus perimeter or urban hotspot deployments and can integrate with RUCKUS management platforms such as SmartZone, ZoneDirector or cloud-based control.
Key Features :
Indoor/Outdoor IP-67 rated rugged housing for outdoor deployment
120° sector integrated antenna for directional outdoor coverage
Dual-band concurrent 2×2:2 MU-MIMO supports up to 1167 Mb/s combined
Single 1 GbE RJ-45 port with PoE and 12 V DC input option
USB 2.0 Type-A port available for IoT dongles or BLE support
Specification :
| Specification | Details |
|---|
| Brand | RUCKUS |
| Part Number | 901-T310-US51 |
| Product Type | Outdoor 802.11ac Wave 2 Access Point |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac Wave 2 |
| Spatial Streams | 2×2:2 |
| Max PHY Rate (2.4 GHz) | Up to 300 Mbps |
| Max PHY Rate (5 GHz) | Up to 867 Mbps |
| Ethernet Port | 1×1 GbE RJ-45 |
| USB Port | 1×USB 2.0 Type A |
| Power Input | PoE 802.3at Class 4, DC 8–20 V |
| Operating Temperature | -40 °C to +65 °C |
| Ingress Protection | IP-67 |
| Antenna Type | 120°×30° sector internal |
| Mounting | Wall, pole bracket included |
| Dimensions (H×W×D) | 4.04 in × 8.23 in × 10.30 in |
| Weight | 3.6 lbs |
