Detailed Specifications
Ruckus 901-R770-US00 – Wi-Fi 7 Tri-Band Indoor Access Point
Overview :
The Ruckus 901-R770-US00 is a high-performance indoor access point designed to meet the demands of modern wireless networks. Leveraging Wi-Fi 7 technology, it offers enhanced throughput, reduced latency, and increased capacity. With a tri-band configuration, it supports 2x2:2 on 2.4 GHz, 4x4:4 on 5 GHz, and 2x2:2 on 6 GHz, delivering a combined maximum PHY rate of 12.22 Gbps. Features like Multi-Link Operation (MLO), Preamble Puncturing, 4K QAM, and 320 MHz channels ensure optimal performance in high-density environments. The R770 is equipped with a 10 Gbps Ethernet port to eliminate backhaul bottlenecks, ensuring full utilization of available Wi-Fi capacity. Its BeamFlex+ technology provides dynamic beamforming, enhancing coverage and reliability. Ideal for large venues such as auditoriums, conference centers, and campuses, the R770 supports up to 1,024 concurrent users.
Key Features :
Tri-band concurrent Wi-Fi 7 support
12.22 Gbps maximum combined data rate
10 Gbps Ethernet port for high-speed backhaul
BeamFlex+ technology for enhanced coverage
Supports up to 1,024 concurrent users
Specifications
| Specification | Details |
|---|
| Brand | Ruckus |
| Part Number | 901-R770-US00 |
| Product Type | Indoor Access Point |
| Wi-Fi Standard | Wi-Fi 7 (802.11be) |
| Frequency Bands | 2.4 GHz, 5 GHz, 6 GHz |
| Radio Configuration | 2x2:2 (2.4 GHz), 4x4:4 (5 GHz), 2x2:2 (6 GHz) |
| Maximum PHY Rate | 12.22 Gbps |
| Ethernet Ports | 1 x 10 Gbps, 1 x 1 Gbps |
| Beamforming | BeamFlex+ |
| Concurrent Users | Up to 1,024 |
| Controller Support | Ruckus One™, SmartZone, Unleashed™, Standalone |
| USB Port | USB 2.0 |
| Mounting Options | Ceiling or wall mountable |
| Operating Temperature | -10°C to 45°C |
