HPEP37545-001

B-Series 10 GbE Short-Wave SFP+ transceiver module (1-Pack)

The HPEP37545-001 B-Series short-wave SFP+ transceiver delivers reliable 10 Gigabit Ethernet over duplex multimode fiber (MMF), utilizing an 850 nm VCSEL optical interface. Designed for data center and enterprise networking gear, this compact, hot-pluggable module supports distances up to 300 m on OM3 and ~400 m on OM4 fiber. Compatible with B-Series, Aruba, and broader HPEnetworking switches, it provides a cost-effective solution for high-speed uplinks and inter-switch connectivity in legacy and modern deployments. Ideal for bandwidth-intensive applications such as server-to-switch links, aggregation rings, and virtualization backbones.

Features

Engineered to meet IEEE 802.3ae 10GBase-SW standards, the P37545-001 is a single-port SFP+ module supporting 10 Gb/s bidirectional throughput. With support for Digital Diagnostic Monitoring (DDM) over I²C, it provides real-time feedback on parameters like optical power, temperature, and voltage. Compatible with HPEB-Series switches and many HPE-validated optics-ready platforms, it supports LC duplex connectors and plug-and-play operation. Whether new or refurbished, modules are tested for HPEinteroperability and backed by a standard 90-day warranty. ([turn0search2]

Advanced Options

Built for stable data center networking, the P37545-001 transceiver reliably maintains full 10 Gb/s speeds with low latency and solid optical margins. The integrated DDM provides drive-level insights for proactive maintenance and monitoring. Constructed with robust metal housing to minimize electromagnetic

Product Key Features

• 10 GbE SR transceiver (850 nm VCSEL) for multimode fiber

• Hot-pluggable SFP+ form factor, LC duplex interface

• Maximum supported distance: ~300 m (OM3), ~400 m (OM4)

• DDM/DOM diagnostic functions via I²C

• Gen-approved for HPEB-Series switching environments

• Available new or refurbished, 1-pack configuration

---

Reliability & Performance

interference, the module ensures thermal and optical integrity in dense switch and uplink deployments. Rigorous compatibility testing and validated support on HPEplatforms ensure predictable interoperability in enterprise fabric designs.

Key Features :

• • 10 GbE over multimode fiber (SR, 850 nm)

  • Duplex LC connector, hot-swappable SFP+ format

  • SR optics for up to 300 m (OM3) or 400 m (OM4)

  • Digital Diagnostic Monitoring (DDM/DOM) support

  • Certified for HPEB-Series switch platforms

  • Packaged in single-unit (1-pack) configuration

Specification	Details
Model Number	P37545-001
Product Type	10 GbE 10GBase-SW SFP+ transceiver module (B-Series)
Interface	Duplex LC connector
Max Data Rate	10 Gbps
Fiber Medium	Multimode fiber (MMF)
Wavelength	850 nm VCSEL
Max Distance	Approx. 300 m (OM3), 400 m (OM4)
DDM Support	Yes, via I²C
Form Factor	Hot-swappable SFP+
Compatibility	HPEB-Series switches and optics-capable HPEplatforms
Condition Options	New or Refurbished
Warranty	90-day standard warranty
