TP-Link TL-SG1016 16-Port Unmanaged Gigabit Switch View larger

TP-Link TL-SG1016 16-Port Unmanaged Gigabit Switch

TL-SG1016

New

In Stock

TP-Link TL-SG1016 16-Port Unmanaged Gigabit Switch

×




dc supplies, 16 Port PoE Switch, TL-SG1016, TP-Link TL-SG1016, TL-SG1016 Switch, TP-Link Switch, 16 port unmanaged gigabit switch, tp-link tl-sg1016 reviews, gigabit ethernet switch 16 port, tp link 16 port switch, best network switch for home off

$74.99

Detailed Specifications

TP-Link TL-SG1016 16-Port Unmanaged Gigabit Switch

Overview :

The TL-SG1016 16-Port Gigabit Switch from TP-Link comes in an energy efficient configuration allowing you to save up to 15% over traditional network switches. With a variety of IEEE standards, including 802.3i, 802.3u, 802.3ab, and 802,3x, this switch can be easily configured to meet a variety of needs. 802.3 compatibility is a general collection of IEEE standards used within a local area network when connecting hubs, switches, and routers. IEEE 802.3u, otherwise known as Fast Ethernet, is a standard that carries traffic at the normal rate of 100 Mbps against the original Ethernet speed of 10 Mbps. The IEEE 802.3x standard refers to a flow control standard allowing you to control traffic throughout the switch.

With 16 x 10/100/1000 Mbps RJ-45 ports, you can connect a number of devices to the Gigabit Switch to allow for multiple devices to connect to the Internet. The 32 Gbps switching capacity provides for ultra fast data transfer speeds along with the 8K MAC address table giving you the necessary space to store a large number of MAC addresses. Auto MDI/MDIX eliminates the need for crossover cables allowing for a seamless connection.

The TL-SG1016 16-Port Gigabit Switch operates using 100-240 VAC at 50/60 Hz and consumes a maximum of 13.3W. It has a packet forwarding rate of 23.8 Mbps and includes a power cord, rackmount kits, and rubber feet. It is protected by a limited 5-year warranty.

TP-LINK Green Technology
The TL-SG1016 Gigabit Switch features innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU'S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled

Specifications :

Product Name 16-Port Gigabit Switch
Product Type Ethernet Switch
Manageable No
Ethernet Technology Gigabit Ethernet
Media Type Supported Twisted Pair
Total Number of Network Ports 16
PoE (RJ-45) Port No
Form Factor Desktop

Rack-mountable

Power Consumption 9.26 W
Power Source Power Supply
Layer Supported 2
Environmentally Friendly Yes
Network (RJ-45) Yes
Port / Expansion Slot Details 16 x Gigabit Ethernet Network
Networking Standards IEEE 802.3i

IEEE 802.3u

IEEE 802.3ab

IEEE 802.3x

Height 1.7"
Width 17.3"
Depth 7.1"
Product Model TL-SG1016
Network Technology 10/100/1000Base-T
Package Contents
  • TL-SG1016 16-Port Gigabit Switch
  • Power Cord
  • Installation Guide
  • Rackmount Kits
  • Rubber Feet
Limited Warranty 3 Year
Number of Network (RJ-45) Ports 16
Product Color Black
System Requirements Operating Systems:
  • Microsoft Windows XP, Vista , Windows 7 or Windows 8
  • MAC OS X
  • NetWare
  • UNIX
  • Linux
