Ubiquiti USW-EnterpriseXG-24
24-Port Layer 3 10G Managed Switch - Scalable High-Speed Enterprise Network Solution
The Ubiquiti USW-EnterpriseXG-24 is a fully managed Layer 3 multi-gigabit switch designed for high-bandwidth networks, data centers, and enterprise-grade infrastructures. Equipped with 24 high-speed 10G RJ45 Ethernet ports and 2 ultra-fast 25G SFP28 uplink ports, this switch delivers enterprise-level performance and future-proof scalability in a compact 1U rack-mount form factor.
Features :
This high-performance switch features 24x 10G RJ45 ports for high-speed connectivity and 2x 25G SFP28 ports for fiber uplinks, providing versatile connectivity options for modern networks. With a massive 580 Gb/s switching capacity (290 Gb/s non-blocking) and 431.52 Mpps forwarding rate, it handles large data volumes with ease, making it ideal for aggregating top-of-rack switch , servers, and storage appliances. The integrated 1.3" LCM touchscreen offers convenient local management, while centralized UniFi Network Application support enables remote configuration and monitoring across distributed networks.
Advanced Options :
The USW-EnterpriseXG-24 offers multiple management options to suit your deployment needs. The built-in LCM color touchscreen displays real-time device information, port statuses, and troubleshooting data directly from the front panel, reducing the need for external consoles during installation and maintenance. For centralized management, the UniFi Network Application allows administrators to configure, monitor, and update devices across distributed networks from a unified interface. This cloud-accessible software platform offers advanced network insights, remote firmware updates, and intuitive VLAN and routing configurations without requiring CLI expertise. With Layer 3 functionality for routing between VLANs and networks, it increases performance in segmented environments while maintaining high throughput.
Product Key Features
- 24x 10G RJ45 ports for high-speed connectivity
- 2x 25G SFP28 ports for fiber uplinks
- Layer 3 switch with 580 Gb/s switching capacity
- Integrated 1.3" LCM touchscreen for local management
- Centralized UniFi Network Application support
- Rack-mountable steel chassis with efficient power design
Reliability & Performance :
Built with galvanized cold-rolled steel (SGCC), the USW-EnterpriseXG-24 provides a durable and thermally efficient housing that ensures reliable operation in demanding environments. The switch supports dual power inputs (AC and DC), providing redundancy and maximizing uptime in mission-critical applications. Its massive 580 Gb/s switch capacity and high forwarding rate of 431.52 Mpps ensure consistent performance even under heavy network loads, making it ideal for data centers, enterprise backbones, and high-density computing environments. The modular, rack-mountable design and energy-efficient operation make it a strong fit for aggregation layers in enterprise networks, whether handling cloud-hosted applications, IP surveillance, or distributed file systems.
