ENET JL310A-40K-ENC Aruba Compatible 100GBASE-LR4 QSFP28 40km LC DOM Transceiver

HPE JL310A-40K-ENC

ENET Aruba Compatible 100GBASE-LR4 QSFP28 40km LC DOM Transceiver

An Aruba compatibleQSFP28 transceiver module for 100 Gigabit Ethernet, providing reliable, long-distance data transmission up to 40 km over single-mode fiber with integrated diagnostics.

Overview:

The ENET JL310A-40K-ENC is an Aruba compatibleQSFP28 transceiver module designed to support 100 Gigabit Ethernet connections over single-mode fiber up to 40 km. It operates according to IEEE 802.3bs 100GBASE-LR4 standards, using 4 lanes of 25Gbps data transmission multiplexed via CWDM technology. The module features an industry-standard LC duplex connector and is hot-swappable. It also supports Digital Optical Monitoring (DOM) for real-time monitoring of parameters such as temperature and optical power.

The JL310A-40K-ENC ensures seamless integration with Aruba switches and other compliant devices, making it ideal for data center and metropolitan area connections. Its rugged design ensures reliable operation in a temperature range from 0°C to 70°C. The device complies with stringent industry standards and environmental regulations, ensuring interoperability and sustainability.

Product Key Features

• 100GBASE-LR4 QSFP28 transceiver module
• LC Duplex single-mode fiber connector
• Supports up to 40 kilometers transmission distance
• CWDM wavelength multiplexing technology
• Compliant with IEEE 802.3bs 100G Ethernet standard
• Digital Optical Monitoring (DOM) support

---

Reliability & Performance:

Manufactured to high standards, this transceiver module delivers stable, low-latency performance over extended distances. The integrated DOM support enables proactive network maintenance and troubleshooting to minimize downtime. Tested for interoperability and compatibility, the device offers a long operational life and reliable connectivity in critical network links.

Key Features:

• 100GBASE-LR4 QSFP28 transceiver
• LC Duplex single-mode fiber interface
• 40 km maximum transmission distance
• CWDM wavelength multiplexing
• IEEE 802.3bs compliant
• Digital Optical Monitoring (DOM)

Technical Specification Table:

Specification	Details
Model Number	JL310A-40K-ENC
Product Type	QSFP28 100 Gigabit Ethernet Module
Speed	100 Gbps
Standard	IEEE 802.3bs 100GBASE-LR4
Connector Type	LC Duplex
Fiber Type	Single-mode fiber (SMF)
Transmission Distance	Up to 40 kilometers
Wavelength	CWDM
Digital Diagnostics Monitoring	Yes
Operating Temperature	0°C to 70°C
Form Factor	QSFP28
Compliance	MSA Compliant, RoHS
