Accortec AA1419062-E6-ACC 1-Port 1000Base-CWDM SFP Module View larger
Previous Next

Accortec AA1419062-E6-ACC 1-Port 1000Base-CWDM SFP Module

New

1-Port Gigabit CWDM SFP Transceiver, 1490 nm, LC Connector
×




  • New

Detailed Specifications

Accortec AA1419062-E6-ACC

1-Port 1000Base-CWDM SFP Module – 1490nm, 80km, LC Duplex

The Accortec AA1419062-E6-ACC 1-Port 1000Base-CWDM SFP Module is designed to support the needs of modern, high-speed network environments. Leveraging Coarse Wavelength Division Multiplexing (CWDM) technology, this optical transceiver allows efficient use of fiber infrastructure by transmitting data at a 1490 nm wavelength—ideal for extending network capacity without additional cabling.

Features :

This 1-Port 1000Base-CWDM SFP optical transceiver operates at 1490 nm wavelength for CWDM networks with an LC Duplex connector for easy and secure setup. It supports Gigabit Ethernet over single-mode fiber and is hot-swappable for zero-downtime upgrades. The module offers a transmission range up to 80 km depending on fiber quality.

Advanced Options :

Installation is quick and secure thanks to the LC Duplex connector and hot-swappable form factor. No downtime is required for upgrades or replacements, making this module ideal for mission-critical environments. Supporting Gigabit Ethernet, it delivers the speed needed for data-intensive applications such as video streaming, VoIP, and large-scale data transfers. Compatibility with 9 μm single-mode fiber makes it a drop-in solution for most fiber optic installations.

Product Key Features

  • 1-Port 1000Base-CWDM SFP optical transceiver
  • Operates at 1490 nm wavelength for CWDM networks
  • LC Duplex connector for easy and secure setup
  • Supports Gigabit Ethernet over single-mode fiber
  • Hot-swappable for zero-downtime upgrades
  • Transmission range up to 80 km depending on fiber

Reliability & Performance :

Built for long-haul performance, the AA1419062-E6-ACC can support distances up to 80 kilometers (depending on link quality), making it suitable for campus backbones and metro area networks. It also features Digital Diagnostics Monitoring (DDM), allowing for proactive maintenance by monitoring key transceiver parameters like optical output power, input power, and temperature. With low power consumption and a compact form factor, the module is optimized for space-efficient networking racks and high-density deployments.

Key Features :

  • 1-Port 1000Base-CWDM Optical Transceiver
  • 1490 nm CWDM wavelength for fiber efficiency
  • LC Duplex connector for easy integration
  • Supports transmission up to 80 km on SMF
  • Hot-swappable SFP design
  • MSA-compliant and Cisco-compatible
  • Supports Digital Diagnostics Monitoring (DDM)

Specifications :

SpecificationDetails
Model Number AA1419062-E6-ACC
Brand Accortec
Type CWDM SFP Optical Transceiver Module
Port Count 1-Port
Data Rate 1 Gbps (Gigabit Ethernet)
Wavelength 1490 nm
Connector Type LC Duplex
Transmission Distance Up to 80 km (single-mode fiber)
Interface SFP (Hot-pluggable)
Form Factor SFP
Power Consumption <1.5W
Operating Temperature 0°C to 70°C
Compatibility MSA Compliant, Cisco-compatible
Fiber Standard 9 μm Single-Mode Fiber
Dimensions Approx. 2.2 x 0.5 x 0.3 inches
Weight Approx. 0.02 lbs
